| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_997T03_9000000216_01151cztM0_level2.evt | modeM0/AS1P01_997T03_9000000216_01151cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,140,226,560 | 103,138,560 |
| Size | 1.1 GB | 98.4 MB |
| Events in quadrant A | 9,424,818 | 655,967 |
| Events in quadrant B | 8,547,075 | 674,534 |
| Events in quadrant C | 8,642,407 | 654,705 |
| Events in quadrant D | 7,455,618 | 652,527 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33015 | 3 |
| B | 0 | 30335 | 2 |
| C | 0 | 30603 | 2 |
| D | 0 | 27168 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6970 | 360 | 5.164993% |
| B | 6970 | 8 | 0.114778% |
| C | 6970 | 14 | 0.200861% |
| D | 6970 | 14 | 0.200861% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7700 | 6971 | 874 | 874 | 11.35% | 12.54% |  |
| B | 7700 | 6971 | 170 | 170 | 2.21% | 2.44% |  |
| C | 7700 | 6971 | 236 | 236 | 3.06% | 3.39% |  |
| D | 7700 | 6971 | 104 | 104 | 1.35% | 1.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 5 | 1449414 | 2913.12 | 2075 | 2095 | 496.8 |
| A | 12 | 243 | 13519 | 22.99 | 2075 | 2095 | 496.8 |
| A | 11 | 79 | 7826 | 11.54 | 2075 | 2095 | 496.8 |
| B | 8 | 4 | 24227 | 41.88 | 2221 | 2227 | 525.3 |
| B | 0 | 220 | 21995 | 37.63 | 2221 | 2227 | 525.3 |
| B | 15 | 22 | 19808 | 33.47 | 2221 | 2227 | 525.3 |
| C | 15 | 241 | 311920 | 541.47 | 2046 | 2121 | 572.1 |
| C | 12 | 206 | 201835 | 349.07 | 2046 | 2121 | 572.1 |
| C | 9 | 83 | 62279 | 105.15 | 2046 | 2121 | 572.1 |
| D | 13 | 138 | 34873 | 54.06 | 1962 | 2038 | 607.4 |
| D | 13 | 252 | 25714 | 38.98 | 1962 | 2038 | 607.4 |
| D | 2 | 152 | 20790 | 30.87 | 1962 | 2038 | 607.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
