| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G04_007T02_9000000220_01193cztM0_level2.evt | modeM0/AS1G04_007T02_9000000220_01193cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,355,742,720 | 103,780,800 |
| Size | 1.3 GB | 99.0 MB |
| Events in quadrant A | 9,040,499 | 713,261 |
| Events in quadrant B | 9,287,268 | 705,038 |
| Events in quadrant C | 8,855,041 | 680,756 |
| Events in quadrant D | 13,394,419 | 535,623 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32068 | 2 |
| B | 0 | 32759 | 1 |
| C | 0 | 31484 | 1 |
| D | 0 | 45324 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7287 | 20 | 0.274461% |
| B | 7287 | 21 | 0.288184% |
| C | 7287 | 8 | 0.109785% |
| D | 7287 | 2217 | 30.424043% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7712 | 7287 | 345 | 345 | 4.47% | 4.73% |  |
| B | 7712 | 7287 | 344 | 344 | 4.46% | 4.72% |  |
| C | 7712 | 7287 | 183 | 183 | 2.37% | 2.51% |  |
| D | 7712 | 7288 | 2993 | 2993 | 38.81% | 41.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 32 | 387506 | 718.27 | 2231 | 2247 | 536.4 |
| A | 8 | 14 | 71025 | 128.23 | 2231 | 2247 | 536.4 |
| A | 0 | 51 | 14040 | 21.99 | 2231 | 2247 | 536.4 |
| B | 6 | 53 | 237945 | 428.74 | 2328 | 2339 | 549.5 |
| B | 10 | 244 | 50890 | 88.35 | 2328 | 2339 | 549.5 |
| B | 5 | 191 | 38025 | 64.94 | 2328 | 2339 | 549.5 |
| C | 15 | 241 | 414057 | 687.82 | 2137 | 2211 | 598.8 |
| C | 3 | 79 | 41007 | 64.79 | 2137 | 2211 | 598.8 |
| C | 3 | 111 | 33000 | 51.42 | 2137 | 2211 | 598.8 |
| D | 1 | 239 | 6327107 | 12158.74 | 1701 | 1762 | 520.2 |
| D | 12 | 22 | 326949 | 625.08 | 1701 | 1762 | 520.2 |
| D | 10 | 84 | 99287 | 187.46 | 1701 | 1762 | 520.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
