| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G04_003T02_9000000224_01232cztM0_level2.evt | modeM0/AS1G04_003T02_9000000224_01232cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,141,272,000 | 99,498,240 |
| Size | 1.1 GB | 94.9 MB |
| Events in quadrant A | 7,811,903 | 667,036 |
| Events in quadrant B | 8,218,778 | 665,008 |
| Events in quadrant C | 7,804,151 | 639,164 |
| Events in quadrant D | 10,293,464 | 583,361 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27896 | 2 |
| B | 0 | 29097 | 1 |
| C | 0 | 27864 | 1 |
| D | 0 | 35466 | 25 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6575 | 48 | 0.730038% |
| B | 6575 | 73 | 1.110266% |
| C | 6575 | 66 | 1.003802% |
| D | 6572 | 1259 | 19.157030% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7506 | 6576 | 235 | 235 | 3.13% | 3.57% |  |
| B | 7506 | 6576 | 303 | 303 | 4.04% | 4.61% |  |
| C | 7506 | 6577 | 258 | 258 | 3.44% | 3.92% |  |
| D | 7505 | 6573 | 1571 | 1571 | 20.93% | 23.90% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 80 | 36118 | 70.42 | 2021 | 2039 | 483.9 |
| A | 15 | 233 | 12957 | 22.56 | 2021 | 2039 | 483.9 |
| A | 12 | 243 | 8103 | 12.53 | 2021 | 2039 | 483.9 |
| B | 5 | 191 | 124913 | 247.59 | 2089 | 2098 | 496.0 |
| B | 15 | 22 | 69064 | 135.0 | 2089 | 2098 | 496.0 |
| B | 3 | 204 | 37482 | 71.33 | 2089 | 2098 | 496.0 |
| C | 15 | 241 | 344797 | 658.67 | 1865 | 1920 | 520.6 |
| C | 10 | 19 | 123851 | 234.23 | 1865 | 1920 | 520.6 |
| C | 3 | 111 | 22461 | 39.46 | 1865 | 1920 | 520.6 |
| D | 12 | 22 | 3693264 | 6858.41 | 1731 | 1790 | 538.2 |
| D | 10 | 85 | 58924 | 106.15 | 1731 | 1790 | 538.2 |
| D | 2 | 170 | 41478 | 73.74 | 1731 | 1790 | 538.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
