| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G04_011T02_9000000226_01281cztM0_level2.evt | modeM0/AS1G04_011T02_9000000226_01281cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,407,196,800 | 96,569,280 |
| Size | 1.3 GB | 92.1 MB |
| Events in quadrant A | 7,909,843 | 649,893 |
| Events in quadrant B | 10,216,701 | 627,566 |
| Events in quadrant C | 8,006,047 | 629,880 |
| Events in quadrant D | 16,045,327 | 550,044 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28272 | 2 |
| B | 0 | 35101 | 1 |
| C | 0 | 28524 | 1 |
| D | 0 | 52547 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6688 | 12 | 0.179426% |
| B | 6688 | 300 | 4.485646% |
| C | 6688 | 20 | 0.299043% |
| D | 6688 | 1694 | 25.328947% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7293 | 6688 | 177 | 177 | 2.43% | 2.65% |  |
| B | 7293 | 6688 | 1251 | 1251 | 17.15% | 18.71% |  |
| C | 7293 | 6689 | 157 | 157 | 2.15% | 2.35% |  |
| D | 7293 | 6688 | 4841 | 4841 | 66.38% | 72.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 14 | 14459 | 25.03 | 2050 | 2067 | 495.2 |
| A | 10 | 2 | 8797 | 13.59 | 2050 | 2067 | 495.2 |
| A | 11 | 79 | 7942 | 11.87 | 2050 | 2067 | 495.2 |
| B | 8 | 4 | 1126075 | 2258.84 | 2099 | 2107 | 497.6 |
| B | 4 | 216 | 355001 | 709.21 | 2099 | 2107 | 497.6 |
| B | 5 | 191 | 241714 | 481.54 | 2099 | 2107 | 497.6 |
| C | 15 | 241 | 351811 | 660.43 | 1895 | 1959 | 529.7 |
| C | 8 | 208 | 125190 | 232.63 | 1895 | 1959 | 529.7 |
| C | 3 | 79 | 55591 | 101.24 | 1895 | 1959 | 529.7 |
| D | 13 | 169 | 8777983 | 16194.3 | 1738 | 1798 | 541.9 |
| D | 13 | 70 | 427790 | 786.06 | 1738 | 1798 | 541.9 |
| D | 10 | 84 | 154105 | 281.05 | 1738 | 1798 | 541.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
