| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G04_002T02_9000000230_01357cztM0_level2.evt | modeM0/AS1G04_002T02_9000000230_01357cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,079,064,000 | 93,936,960 |
| Size | 1.0 GB | 89.6 MB |
| Events in quadrant A | 10,170,982 | 586,692 |
| Events in quadrant B | 7,969,115 | 618,774 |
| Events in quadrant C | 7,359,200 | 605,576 |
| Events in quadrant D | 6,768,404 | 599,194 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34674 | 2 |
| B | 0 | 28074 | 1 |
| C | 0 | 26250 | 1 |
| D | 0 | 24571 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6216 | 566 | 9.105534% |
| B | 6216 | 37 | 0.595238% |
| C | 6216 | 11 | 0.176963% |
| D | 6216 | 14 | 0.225225% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7241 | 6216 | 1475 | 1475 | 20.37% | 23.73% |  |
| B | 7241 | 6217 | 301 | 301 | 4.16% | 4.84% |  |
| C | 7241 | 6216 | 146 | 146 | 2.02% | 2.35% |  |
| D | 7241 | 6216 | 143 | 143 | 1.97% | 2.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 127 | 3086116 | 7074.56 | 1815 | 1826 | 436.0 |
| A | 4 | 32 | 75285 | 168.5 | 1815 | 1826 | 436.0 |
| A | 12 | 243 | 24319 | 51.59 | 1815 | 1826 | 436.0 |
| B | 10 | 213 | 165922 | 356.84 | 1959 | 1967 | 459.5 |
| B | 5 | 191 | 152826 | 328.33 | 1959 | 1967 | 459.5 |
| B | 8 | 4 | 54888 | 115.18 | 1959 | 1967 | 459.5 |
| C | 15 | 241 | 178247 | 346.88 | 1824 | 1890 | 508.4 |
| C | 3 | 79 | 23139 | 41.79 | 1824 | 1890 | 508.4 |
| C | 3 | 111 | 23032 | 41.58 | 1824 | 1890 | 508.4 |
| D | 9 | 53 | 41427 | 72.96 | 1753 | 1818 | 542.9 |
| D | 9 | 64 | 32982 | 57.4 | 1753 | 1818 | 542.9 |
| D | 12 | 22 | 31239 | 54.19 | 1753 | 1818 | 542.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
