| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G02_020T01_9000000296_01799cztM0_level2.evt | modeM0/AS1G02_020T01_9000000296_01799cztM0_level2_quad_clean.evt |
| Size (bytes) | 958,449,600 | 75,078,720 |
| Size | 914.0 MB | 71.6 MB |
| Events in quadrant A | 7,147,256 | 472,245 |
| Events in quadrant B | 7,307,819 | 480,618 |
| Events in quadrant C | 6,877,128 | 465,924 |
| Events in quadrant D | 7,314,383 | 453,659 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25337 | 2 |
| B | 0 | 25765 | 2 |
| C | 0 | 24500 | 2 |
| D | 0 | 25829 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5736 | 34 | 0.592748% |
| B | 5736 | 31 | 0.540446% |
| C | 5736 | 35 | 0.610181% |
| D | 5736 | 133 | 2.318689% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5806 | 5739 | 409 | 409 | 7.04% | 7.13% |  |
| B | 5806 | 5739 | 412 | 412 | 7.10% | 7.18% |  |
| C | 5806 | 5739 | 344 | 344 | 5.92% | 5.99% |  |
| D | 5806 | 5739 | 529 | 529 | 9.11% | 9.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 231 | 71790 | 154.93 | 1850 | 1863 | 451.3 |
| A | -1 | -1 | -1 | -1.0 | 1850 | 1863 | 451.3 |
| A | -1 | -1 | -1 | -1.0 | 1850 | 1863 | 451.3 |
| B | 15 | 85 | 10726 | 19.24 | 1919 | 1929 | 457.2 |
| B | 0 | 220 | 10595 | 18.96 | 1919 | 1929 | 457.2 |
| B | 4 | 200 | 9043 | 15.56 | 1919 | 1929 | 457.2 |
| C | 10 | 82 | 26368 | 49.96 | 1749 | 1816 | 491.5 |
| C | 9 | 236 | 12553 | 21.85 | 1749 | 1816 | 491.5 |
| C | 2 | 53 | 12012 | 20.75 | 1749 | 1816 | 491.5 |
| D | 13 | 53 | 359347 | 670.43 | 1712 | 1768 | 533.4 |
| D | 7 | 85 | 286746 | 534.31 | 1712 | 1768 | 533.4 |
| D | 13 | 169 | 106005 | 195.44 | 1712 | 1768 | 533.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
