| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_055T01_9000000314_01927cztM0_level2.evt | modeM0/AS1T01_055T01_9000000314_01927cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,075,498,560 | 105,871,680 |
| Size | 1.0 GB | 101.0 MB |
| Events in quadrant A | 8,247,358 | 685,134 |
| Events in quadrant B | 8,542,927 | 698,763 |
| Events in quadrant C | 7,868,395 | 685,900 |
| Events in quadrant D | 7,466,245 | 666,958 |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7640 | 6734 | 237 | 237 | 3.10% | 3.52% |  |
| B | 7640 | 6736 | 307 | 307 | 4.02% | 4.56% |  |
| C | 7640 | 6736 | 197 | 197 | 2.58% | 2.92% |  |
| D | 7640 | 6736 | 184 | 184 | 2.41% | 2.73% |  |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
