| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_175T03_9000000322_02097cztM0_level2.evt | modeM0/AS1P01_175T03_9000000322_02097cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,039,680,000 | 109,036,800 |
| Size | 991.5 MB | 104.0 MB |
| Events in quadrant A | 7,868,587 | 726,372 |
| Events in quadrant B | 8,422,473 | 727,911 |
| Events in quadrant C | 7,528,152 | 711,547 |
| Events in quadrant D | 7,249,824 | 696,372 |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7512 | 6308 | 269 | 269 | 3.58% | 4.26% |  |
| B | 7512 | 6308 | 351 | 351 | 4.67% | 5.56% |  |
| C | 7512 | 6308 | 171 | 171 | 2.28% | 2.71% |  |
| D | 7512 | 6308 | 205 | 205 | 2.73% | 3.25% |  |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
