| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_072T02_9000000336_02148cztM0_level2.evt | modeM0/AS1T01_072T02_9000000336_02148cztM0_level2_quad_clean.evt |
| Size (bytes) | 484,352,640 | 78,197,760 |
| Size | 461.9 MB | 74.6 MB |
| Events in quadrant A | 4,886,747 | 445,486 |
| Events in quadrant B | 3,343,569 | 484,012 |
| Events in quadrant C | 2,988,901 | 470,741 |
| Events in quadrant D | 2,955,230 | 461,782 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20199 | 5 |
| B | 0 | 15295 | 1 |
| C | 0 | 14781 | 1 |
| D | 0 | 15007 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 1 | 1 | 0 |
| C | 1 | -1 | -1 |
| D | 1 | -1 | -1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7267 | 817 | 11.242604% |
| B | 7269 | 65 | 0.894208% |
| C | 7269 | 23 | 0.316412% |
| D | 7269 | 40 | 0.550282% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7549 | 7269 | 186 | 186 | 2.46% | 2.56% |  |
| B | 7549 | 7270 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7549 | 7270 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7549 | 7270 | 20 | 20 | 0.26% | 0.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 171 | 2159082 | 15205.16 | 709 | 697 | 142.0 |
| A | 15 | 175 | 5493 | 33.79 | 709 | 697 | 142.0 |
| A | 0 | 1 | 4518 | 26.92 | 709 | 697 | 142.0 |
| B | 5 | 68 | 231281 | 1584.27 | 794 | 781 | 145.5 |
| B | 0 | 245 | 27463 | 183.39 | 794 | 781 | 145.5 |
| B | 5 | 189 | 15338 | 100.05 | 794 | 781 | 145.5 |
| C | 12 | 4 | 22485 | 131.12 | 753 | 757 | 165.7 |
| C | 1 | 192 | 13109 | 74.54 | 753 | 757 | 165.7 |
| C | 10 | 82 | 2477 | 10.38 | 753 | 757 | 165.7 |
| D | 10 | 199 | 65807 | 383.3 | 741 | 724 | 169.8 |
| D | 13 | 53 | 43064 | 249.36 | 741 | 724 | 169.8 |
| D | 9 | 64 | 25685 | 147.01 | 741 | 724 | 169.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
