| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_072T05_9000000344_02230cztM0_level2.evt | modeM0/AS1T01_072T05_9000000344_02230cztM0_level2_quad_clean.evt |
| Size (bytes) | 409,530,240 | 74,707,200 |
| Size | 390.6 MB | 71.2 MB |
| Events in quadrant A | 2,973,794 | 452,627 |
| Events in quadrant B | 3,051,813 | 457,891 |
| Events in quadrant C | 3,019,103 | 456,711 |
| Events in quadrant D | 2,920,659 | 446,427 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13301 | 2 |
| B | 0 | 13377 | 2 |
| C | 0 | 13305 | 2 |
| D | 0 | 13410 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 1 | 1 | 0 |
| C | 1 | -1 | -1 |
| D | 1 | -1 | -1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6422 | 65 | 1.012146% |
| B | 6422 | 65 | 1.012146% |
| C | 6422 | 61 | 0.949860% |
| D | 6422 | 55 | 0.856431% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7577 | 6423 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7577 | 6423 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7577 | 6423 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7577 | 6423 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 194 | 8678 | 50.17 | 771 | 753 | 158.0 |
| A | 0 | 226 | 8134 | 46.73 | 771 | 753 | 158.0 |
| A | 3 | 1 | 3593 | 17.98 | 771 | 753 | 158.0 |
| B | 14 | 53 | 14947 | 93.83 | 786 | 767 | 151.1 |
| B | 12 | 111 | 10915 | 67.15 | 786 | 767 | 151.1 |
| B | 11 | 111 | 9255 | 56.17 | 786 | 767 | 151.1 |
| C | 1 | 192 | 14852 | 78.33 | 764 | 769 | 179.8 |
| C | 5 | 234 | 10790 | 55.73 | 764 | 769 | 179.8 |
| C | 13 | 61 | 7027 | 34.81 | 764 | 769 | 179.8 |
| D | 2 | 152 | 27012 | 146.34 | 752 | 733 | 179.6 |
| D | 2 | 63 | 23456 | 126.54 | 752 | 733 | 179.6 |
| D | 15 | 194 | 13963 | 73.68 | 752 | 733 | 179.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
