| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_058T01_9000000348_02298cztM0_level2.evt | modeM0/AS1T01_058T01_9000000348_02298cztM0_level2_quad_clean.evt |
| Size (bytes) | 313,464,960 | 51,822,720 |
| Size | 298.9 MB | 49.4 MB |
| Events in quadrant A | 1,955,272 | 308,935 |
| Events in quadrant B | 2,389,962 | 314,339 |
| Events in quadrant C | 2,165,914 | 314,006 |
| Events in quadrant D | 2,663,765 | 303,885 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 96 | 0 |
| B | 0 | 96 | 0 |
| C | 0 | 96 | 0 |
| D | 0 | 96 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9427 | 0 |
| B | 0 | 10170 | 0 |
| C | 0 | 9678 | 0 |
| D | 0 | 11469 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4662 | 21 | 0.450450% |
| B | 4662 | 55 | 1.179751% |
| C | 4662 | 9 | 0.193050% |
| D | 4662 | 192 | 4.118404% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5747 | 4662 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5747 | 4662 | 0 | 0 | 0.00% | 0.00% |  |
| C | 5746 | 4661 | 2 | 2 | 0.03% | 0.04% |  |
| D | 5747 | 4663 | 112 | 112 | 1.95% | 2.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 194 | 5768 | 49.77 | 508 | 497 | 105.9 |
| A | 0 | 226 | 5680 | 48.94 | 508 | 497 | 105.9 |
| A | 8 | 35 | 1160 | 6.26 | 508 | 497 | 105.9 |
| B | 4 | 48 | 393818 | 3959.86 | 510 | 496 | 99.3 |
| B | 8 | 3 | 24391 | 240.57 | 510 | 496 | 99.3 |
| B | 15 | 85 | 7756 | 73.09 | 510 | 496 | 99.3 |
| C | 5 | 234 | 161759 | 1377.0 | 495 | 496 | 117.1 |
| C | 10 | 65 | 24190 | 202.32 | 495 | 496 | 117.1 |
| C | 8 | 112 | 24109 | 201.63 | 495 | 496 | 117.1 |
| D | 9 | 66 | 823656 | 7102.61 | 484 | 471 | 115.9 |
| D | 15 | 194 | 8806 | 71.92 | 484 | 471 | 115.9 |
| D | 14 | 226 | 5582 | 44.1 | 484 | 471 | 115.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
