| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_056T01_9000000356_02329cztM0_level2.evt | modeM0/AS1T01_056T01_9000000356_02329cztM0_level2_quad_clean.evt |
| Size (bytes) | 362,603,520 | 64,238,400 |
| Size | 345.8 MB | 61.3 MB |
| Events in quadrant A | 2,617,940 | 396,474 |
| Events in quadrant B | 2,700,979 | 400,195 |
| Events in quadrant C | 2,741,138 | 389,815 |
| Events in quadrant D | 2,551,183 | 378,027 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11208 | 2 |
| B | 0 | 11335 | 1 |
| C | 0 | 11530 | 1 |
| D | 0 | 11262 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5438 | 81 | 1.489518% |
| B | 5438 | 65 | 1.195292% |
| C | 5438 | 51 | 0.937845% |
| D | 5438 | 66 | 1.213682% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6658 | 5439 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6658 | 5439 | 3 | 3 | 0.05% | 0.06% |  |
| C | 6658 | 5439 | 3 | 3 | 0.05% | 0.06% |  |
| D | 6658 | 5439 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7921 | 52.26 | 678 | 665 | 138.8 |
| A | 12 | 194 | 7890 | 52.04 | 678 | 665 | 138.8 |
| A | 0 | 149 | 7173 | 46.87 | 678 | 665 | 138.8 |
| B | 8 | 3 | 45032 | 338.48 | 679 | 663 | 131.1 |
| B | 15 | 54 | 18416 | 135.43 | 679 | 663 | 131.1 |
| B | 15 | 85 | 9402 | 66.67 | 679 | 663 | 131.1 |
| C | 5 | 234 | 112747 | 732.85 | 655 | 661 | 152.9 |
| C | 12 | 4 | 39636 | 254.83 | 655 | 661 | 152.9 |
| C | 10 | 65 | 14791 | 92.39 | 655 | 661 | 152.9 |
| D | 15 | 194 | 12362 | 75.39 | 657 | 642 | 155.5 |
| D | 13 | 238 | 10095 | 60.8 | 657 | 642 | 155.5 |
| D | 10 | 172 | 9641 | 57.88 | 657 | 642 | 155.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
