| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G02_018T06_9000000370_02456cztM0_level2.evt | modeM0/AS1G02_018T06_9000000370_02456cztM0_level2_quad_clean.evt |
| Size (bytes) | 606,294,720 | 85,392,000 |
| Size | 578.2 MB | 81.4 MB |
| Events in quadrant A | 3,325,507 | 537,759 |
| Events in quadrant B | 3,517,366 | 553,138 |
| Events in quadrant C | 7,758,097 | 441,198 |
| Events in quadrant D | 3,251,237 | 531,005 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15202 | 3 |
| B | 0 | 15507 | 2 |
| C | 0 | 28399 | 2 |
| D | 0 | 15350 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7503 | 34 | 0.453152% |
| B | 7503 | 37 | 0.493136% |
| C | 7503 | 1992 | 26.549380% |
| D | 7503 | 29 | 0.386512% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9398 | 7505 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9398 | 7505 | 1 | 1 | 0.01% | 0.01% |  |
| C | 9398 | 7505 | 1752 | 1752 | 18.64% | 23.34% |  |
| D | 9398 | 7505 | 3 | 3 | 0.03% | 0.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 194 | 9607 | 49.5 | 859 | 840 | 177.1 |
| A | 0 | 226 | 9290 | 47.71 | 859 | 840 | 177.1 |
| A | 13 | 9 | 8686 | 44.3 | 859 | 840 | 177.1 |
| B | 10 | 244 | 90430 | 529.44 | 878 | 856 | 169.2 |
| B | 10 | 224 | 15719 | 87.85 | 878 | 856 | 169.2 |
| B | 4 | 200 | 12481 | 68.71 | 878 | 856 | 169.2 |
| C | 2 | 53 | 4942683 | 30087.5 | 707 | 709 | 164.3 |
| C | 12 | 4 | 18183 | 106.38 | 707 | 709 | 164.3 |
| C | 8 | 208 | 16055 | 93.43 | 707 | 709 | 164.3 |
| D | 2 | 14 | 36761 | 181.35 | 829 | 808 | 198.2 |
| D | 15 | 194 | 15173 | 72.46 | 829 | 808 | 198.2 |
| D | 2 | 184 | 14261 | 67.86 | 829 | 808 | 198.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
