| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_103T01_9000000374_02519cztM0_level2.evt | modeM0/AS1T01_103T01_9000000374_02519cztM0_level2_quad_clean.evt |
| Size (bytes) | 393,445,440 | 61,966,080 |
| Size | 375.2 MB | 59.1 MB |
| Events in quadrant A | 2,758,323 | 365,599 |
| Events in quadrant B | 2,782,691 | 371,762 |
| Events in quadrant C | 2,750,376 | 364,647 |
| Events in quadrant D | 3,209,726 | 349,041 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12444 | 2 |
| B | 0 | 12449 | 1 |
| C | 0 | 12490 | 1 |
| D | 0 | 13690 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6092 | 88 | 1.444517% |
| B | 6092 | 89 | 1.460932% |
| C | 6092 | 48 | 0.787919% |
| D | 6092 | 149 | 2.445831% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7252 | 6093 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7252 | 6093 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7252 | 6093 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7252 | 6093 | 70 | 70 | 0.97% | 1.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 194 | 7983 | 50.38 | 712 | 699 | 144.6 |
| A | 0 | 226 | 7880 | 49.67 | 712 | 699 | 144.6 |
| A | 0 | 199 | 4346 | 25.23 | 712 | 699 | 144.6 |
| B | 12 | 111 | 11499 | 78.9 | 719 | 702 | 136.8 |
| B | 11 | 111 | 8937 | 60.18 | 719 | 702 | 136.8 |
| B | 8 | 61 | 7352 | 48.59 | 719 | 702 | 136.8 |
| C | 8 | 112 | 26533 | 161.33 | 686 | 689 | 160.2 |
| C | 10 | 82 | 15153 | 90.29 | 686 | 689 | 160.2 |
| C | 8 | 128 | 11033 | 64.57 | 686 | 689 | 160.2 |
| D | 1 | 31 | 264951 | 1654.83 | 673 | 655 | 159.7 |
| D | 11 | 131 | 182321 | 1137.46 | 673 | 655 | 159.7 |
| D | 11 | 130 | 111076 | 691.38 | 673 | 655 | 159.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
