| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_010T01_9000000398_02663cztM0_level2.evt | modeM0/AS1P01_010T01_9000000398_02663cztM0_level2_quad_clean.evt |
| Size (bytes) | 602,533,440 | 98,375,040 |
| Size | 574.6 MB | 93.8 MB |
| Events in quadrant A | 2,888,290 | 660,517 |
| Events in quadrant B | 3,060,855 | 663,703 |
| Events in quadrant C | 8,784,046 | 594,097 |
| Events in quadrant D | 3,087,698 | 619,598 |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7580 | 6321 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7579 | 6320 | 18 | 18 | 0.24% | 0.28% |  |
| C | 7580 | 6321 | 676 | 676 | 8.92% | 10.69% |  |
| D | 7580 | 6321 | 22 | 22 | 0.29% | 0.35% |  |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
