| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_237T02_9000000422_03037cztM0_level2.evt | modeM0/AS1G05_237T02_9000000422_03037cztM0_level2_quad_clean.evt |
| Size (bytes) | 353,488,320 | 75,804,480 |
| Size | 337.1 MB | 72.3 MB |
| Events in quadrant A | 2,076,549 | 494,049 |
| Events in quadrant B | 3,252,183 | 490,627 |
| Events in quadrant C | 2,293,770 | 495,027 |
| Events in quadrant D | 2,754,821 | 477,710 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 96 | 0 |
| B | 0 | 96 | 0 |
| C | 0 | 96 | 0 |
| D | 0 | 96 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9711 | 2 |
| B | 0 | 12975 | 1 |
| C | 0 | 10449 | 1 |
| D | 0 | 11612 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4823 | 8 | 0.165872% |
| B | 4823 | 170 | 3.524777% |
| C | 4823 | 57 | 1.181837% |
| D | 4823 | 153 | 3.172299% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6949 | 4824 | 1 | 1 | 0.01% | 0.02% |  |
| B | 6949 | 4824 | 149 | 149 | 2.14% | 3.09% |  |
| C | 6949 | 4824 | 51 | 51 | 0.73% | 1.06% |  |
| D | 6949 | 4824 | 128 | 128 | 1.84% | 2.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 20652 | 189.43 | 525 | 515 | 106.3 |
| A | 15 | 174 | 9157 | 81.29 | 525 | 515 | 106.3 |
| A | 13 | 251 | 8983 | 79.66 | 525 | 515 | 106.3 |
| B | 15 | 204 | 505220 | 5019.85 | 525 | 514 | 100.5 |
| B | 0 | 230 | 297949 | 2958.32 | 525 | 514 | 100.5 |
| B | 7 | 252 | 120986 | 1198.23 | 525 | 514 | 100.5 |
| C | 1 | 192 | 242555 | 2112.57 | 499 | 502 | 114.6 |
| C | 6 | 80 | 63666 | 551.28 | 499 | 502 | 114.6 |
| C | 1 | 16 | 17384 | 147.34 | 499 | 502 | 114.6 |
| D | 7 | 80 | 290974 | 2474.9 | 497 | 486 | 117.4 |
| D | 13 | 114 | 237111 | 2016.0 | 497 | 486 | 117.4 |
| D | 2 | 152 | 176753 | 1501.76 | 497 | 486 | 117.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
