| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_238T03_9000000424_03068cztM0_level2.evt | modeM0/AS1G05_238T03_9000000424_03068cztM0_level2_quad_clean.evt |
| Size (bytes) | 375,929,280 | 57,807,360 |
| Size | 358.5 MB | 55.1 MB |
| Events in quadrant A | 2,692,842 | 365,602 |
| Events in quadrant B | 3,065,162 | 363,707 |
| Events in quadrant C | 2,566,253 | 350,679 |
| Events in quadrant D | 2,741,010 | 339,829 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10848 | 3 |
| B | 0 | 12254 | 2 |
| C | 0 | 10821 | 2 |
| D | 0 | 11546 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44 | 0 |
| B | 0 | 44 | 0 |
| C | 0 | 44 | 0 |
| D | 0 | 44 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5042 | 10 | 0.198334% |
| B | 5042 | 18 | 0.357001% |
| C | 5042 | 33 | 0.654502% |
| D | 5042 | 33 | 0.654502% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9352 | 5044 | 3 | 3 | 0.03% | 0.06% |  |
| B | 9352 | 5044 | 7 | 7 | 0.07% | 0.14% |  |
| C | 9352 | 5044 | 27 | 27 | 0.29% | 0.54% |  |
| D | 9352 | 5044 | 24 | 24 | 0.26% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 187488 | 1539.07 | 605 | 594 | 121.4 |
| A | 12 | 189 | 108050 | 884.9 | 605 | 594 | 121.4 |
| A | 14 | 238 | 23492 | 188.56 | 605 | 594 | 121.4 |
| B | 15 | 204 | 611728 | 5321.08 | 608 | 597 | 114.9 |
| B | 0 | 219 | 38356 | 328.77 | 608 | 597 | 114.9 |
| B | 2 | 249 | 22099 | 187.22 | 608 | 597 | 114.9 |
| C | 15 | 208 | 76261 | 570.8 | 574 | 578 | 132.6 |
| C | 14 | 223 | 62539 | 467.31 | 574 | 578 | 132.6 |
| C | 6 | 80 | 48645 | 362.52 | 574 | 578 | 132.6 |
| D | 2 | 136 | 134886 | 972.56 | 576 | 561 | 138.1 |
| D | 2 | 152 | 128392 | 925.54 | 576 | 561 | 138.1 |
| D | 12 | 17 | 67264 | 482.95 | 576 | 561 | 138.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
