| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_237T03_9000000426_03086cztM0_level2.evt | modeM0/AS1G05_237T03_9000000426_03086cztM0_level2_quad_clean.evt |
| Size (bytes) | 682,041,600 | 55,627,200 |
| Size | 650.4 MB | 53.1 MB |
| Events in quadrant A | 3,439,118 | 395,576 |
| Events in quadrant B | 7,979,957 | 37,884 |
| Events in quadrant C | 4,169,952 | 390,450 |
| Events in quadrant D | 4,597,115 | 377,816 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14595 | 2 |
| B | 0 | 28302 | 1 |
| C | 0 | 16992 | 1 |
| D | 0 | 18480 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6903 | 126 | 1.825293% |
| B | 6903 | 4708 | 68.202231% |
| C | 6903 | 252 | 3.650587% |
| D | 6903 | 375 | 5.432421% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7393 | 6904 | 5 | 5 | 0.07% | 0.07% |  |
| B | 7393 | 6903 | 694 | 694 | 9.39% | 10.05% |  |
| C | 7393 | 6904 | 105 | 105 | 1.42% | 1.52% |  |
| D | 7393 | 6904 | 226 | 226 | 3.06% | 3.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 182836 | 1097.67 | 807 | 789 | 165.8 |
| A | 12 | 247 | 86336 | 515.81 | 807 | 789 | 165.8 |
| A | 0 | 50 | 34749 | 204.76 | 807 | 789 | 165.8 |
| B | 4 | 81 | 6599611 | 111017.96 | 297 | 290 | 59.4 |
| B | 0 | 230 | 64029 | 1072.26 | 297 | 290 | 59.4 |
| B | 3 | 0 | 43488 | 726.7 | 297 | 290 | 59.4 |
| C | 14 | 223 | 415866 | 2290.51 | 771 | 777 | 181.2 |
| C | 15 | 208 | 353699 | 1947.47 | 771 | 777 | 181.2 |
| C | 5 | 250 | 123863 | 679.2 | 771 | 777 | 181.2 |
| D | 13 | 223 | 484107 | 2334.04 | 763 | 746 | 207.1 |
| D | 13 | 114 | 324909 | 1565.31 | 763 | 746 | 207.1 |
| D | 2 | 136 | 305079 | 1469.55 | 763 | 746 | 207.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
