| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_237T03_9000000426_03095cztM0_level2.evt | modeM0/AS1G05_237T03_9000000426_03095cztM0_level2_quad_clean.evt |
| Size (bytes) | 621,912,960 | 78,788,160 |
| Size | 593.1 MB | 75.1 MB |
| Events in quadrant A | 4,158,716 | 492,371 |
| Events in quadrant B | 3,145,048 | 508,176 |
| Events in quadrant C | 6,427,333 | 474,660 |
| Events in quadrant D | 4,682,079 | 475,694 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16254 | 2 |
| B | 0 | 13445 | 1 |
| C | 0 | 23415 | 1 |
| D | 0 | 18443 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6231 | 91 | 1.460440% |
| B | 6231 | 31 | 0.497512% |
| C | 6231 | 1227 | 19.691863% |
| D | 6231 | 513 | 8.233028% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7406 | 6232 | 73 | 73 | 0.99% | 1.17% |  |
| B | 7406 | 6232 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7406 | 6232 | 921 | 921 | 12.44% | 14.78% |  |
| D | 7406 | 6232 | 395 | 395 | 5.33% | 6.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 249 | 969861 | 6751.1 | 710 | 699 | 143.6 |
| A | 8 | 15 | 384922 | 2676.46 | 710 | 699 | 143.6 |
| A | 12 | 247 | 40042 | 274.06 | 710 | 699 | 143.6 |
| B | 15 | 204 | 183480 | 1309.72 | 733 | 718 | 139.5 |
| B | 0 | 219 | 36081 | 253.42 | 733 | 718 | 139.5 |
| B | 2 | 249 | 25714 | 179.13 | 733 | 718 | 139.5 |
| C | 14 | 223 | 3785004 | 26170.66 | 622 | 626 | 144.6 |
| C | 6 | 80 | 73186 | 501.78 | 622 | 626 | 144.6 |
| C | 1 | 16 | 59633 | 408.06 | 622 | 626 | 144.6 |
| D | 1 | 7 | 1211795 | 7032.41 | 657 | 645 | 172.2 |
| D | 1 | 193 | 730365 | 4237.04 | 657 | 645 | 172.2 |
| D | 13 | 46 | 71818 | 413.26 | 657 | 645 | 172.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
