| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_118T01_9000000430_03143cztM0_level2.evt | modeM0/AS1T01_118T01_9000000430_03143cztM0_level2_quad_clean.evt |
| Size (bytes) | 512,012,160 | 65,321,280 |
| Size | 488.3 MB | 62.3 MB |
| Events in quadrant A | 3,325,598 | 374,303 |
| Events in quadrant B | 3,775,622 | 374,166 |
| Events in quadrant C | 4,240,191 | 372,108 |
| Events in quadrant D | 3,682,023 | 361,676 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14778 | 3 |
| B | 0 | 15897 | 2 |
| C | 0 | 17439 | 2 |
| D | 0 | 15848 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7102 | 189 | 2.661222% |
| B | 7102 | 228 | 3.210363% |
| C | 7102 | 341 | 4.801464% |
| D | 7102 | 195 | 2.745705% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7957 | 7102 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7957 | 7102 | 26 | 26 | 0.33% | 0.37% |  |
| C | 7957 | 7102 | 175 | 175 | 2.20% | 2.46% |  |
| D | 7957 | 7102 | 41 | 41 | 0.52% | 0.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 31 | 26040 | 145.29 | 851 | 833 | 173.5 |
| A | 14 | 249 | 9938 | 52.48 | 851 | 833 | 173.5 |
| A | 12 | 194 | 9243 | 48.48 | 851 | 833 | 173.5 |
| B | 15 | 201 | 131064 | 788.49 | 858 | 838 | 165.2 |
| B | 5 | 70 | 121583 | 731.08 | 858 | 838 | 165.2 |
| B | 4 | 81 | 87236 | 523.12 | 858 | 838 | 165.2 |
| C | 1 | 192 | 629827 | 3284.79 | 822 | 826 | 191.5 |
| C | 14 | 223 | 306313 | 1595.33 | 822 | 826 | 191.5 |
| C | 6 | 80 | 45766 | 234.69 | 822 | 826 | 191.5 |
| D | 2 | 136 | 163786 | 814.42 | 831 | 807 | 200.1 |
| D | 13 | 223 | 97260 | 481.99 | 831 | 807 | 200.1 |
| D | 5 | 233 | 83082 | 411.14 | 831 | 807 | 200.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
