| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_127T01_9000000436_03196cztM0_level2.evt | modeM0/AS1G05_127T01_9000000436_03196cztM0_level2_quad_clean.evt |
| Size (bytes) | 594,512,640 | 84,000,960 |
| Size | 567.0 MB | 80.1 MB |
| Events in quadrant A | 2,735,306 | 555,517 |
| Events in quadrant B | 2,879,658 | 562,273 |
| Events in quadrant C | 8,551,682 | 475,580 |
| Events in quadrant D | 3,427,774 | 526,709 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12392 | 2 |
| B | 0 | 12667 | 1 |
| C | 0 | 29589 | 1 |
| D | 0 | 14554 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6060 | 16 | 0.264026% |
| B | 6060 | 15 | 0.247525% |
| C | 6060 | 1835 | 30.280528% |
| D | 6060 | 107 | 1.765677% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7215 | 6061 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7215 | 6060 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7215 | 6060 | 1874 | 1874 | 25.97% | 30.92% |  |
| D | 7215 | 6061 | 99 | 99 | 1.37% | 1.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 29129 | 198.42 | 700 | 687 | 143.3 |
| A | 0 | 226 | 9866 | 64.03 | 700 | 687 | 143.3 |
| A | 12 | 194 | 7492 | 47.47 | 700 | 687 | 143.3 |
| B | 4 | 80 | 35206 | 249.6 | 717 | 702 | 138.2 |
| B | 0 | 231 | 18825 | 131.1 | 717 | 702 | 138.2 |
| B | 2 | 249 | 15285 | 105.49 | 717 | 702 | 138.2 |
| C | 12 | 206 | 5652610 | 38983.51 | 620 | 626 | 145.0 |
| C | 1 | 192 | 204737 | 1407.82 | 620 | 626 | 145.0 |
| C | 14 | 223 | 138684 | 952.23 | 620 | 626 | 145.0 |
| D | 13 | 223 | 443834 | 2714.27 | 670 | 652 | 163.3 |
| D | 13 | 120 | 149994 | 914.65 | 670 | 652 | 163.3 |
| D | 5 | 233 | 100138 | 609.3 | 670 | 652 | 163.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
