| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_127T01_9000000436_03197cztM0_level2.evt | modeM0/AS1G05_127T01_9000000436_03197cztM0_level2_quad_clean.evt |
| Size (bytes) | 540,403,200 | 89,130,240 |
| Size | 515.4 MB | 85.0 MB |
| Events in quadrant A | 2,950,010 | 575,309 |
| Events in quadrant B | 3,100,033 | 584,504 |
| Events in quadrant C | 6,371,053 | 553,045 |
| Events in quadrant D | 3,516,000 | 544,377 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13099 | 2 |
| B | 0 | 13456 | 2 |
| C | 0 | 23357 | 2 |
| D | 0 | 15024 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6334 | 28 | 0.442059% |
| B | 6334 | 34 | 0.536786% |
| C | 6334 | 448 | 7.072940% |
| D | 6334 | 136 | 2.147142% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7564 | 6335 | 8 | 8 | 0.11% | 0.13% |  |
| B | 7564 | 6334 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7564 | 6334 | 373 | 373 | 4.93% | 5.89% |  |
| D | 7564 | 6335 | 126 | 126 | 1.67% | 1.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 33521 | 213.98 | 750 | 736 | 153.2 |
| A | 3 | 1 | 11887 | 72.78 | 750 | 736 | 153.2 |
| A | 0 | 226 | 10958 | 66.72 | 750 | 736 | 153.2 |
| B | 4 | 80 | 41903 | 278.01 | 770 | 753 | 148.0 |
| B | 0 | 231 | 16208 | 104.41 | 770 | 753 | 148.0 |
| B | 2 | 249 | 13997 | 89.48 | 770 | 753 | 148.0 |
| C | 12 | 206 | 3072217 | 18389.66 | 719 | 724 | 167.0 |
| C | 14 | 223 | 401357 | 2398.67 | 719 | 724 | 167.0 |
| C | 6 | 80 | 37596 | 220.76 | 719 | 724 | 167.0 |
| D | 13 | 223 | 405205 | 2295.44 | 714 | 699 | 176.2 |
| D | 13 | 120 | 136028 | 767.95 | 714 | 699 | 176.2 |
| D | 5 | 233 | 82686 | 465.25 | 714 | 699 | 176.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
