| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_104T01_9000000440_03237cztM0_level2.evt | modeM0/AS1G05_104T01_9000000440_03237cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,006,400 | 89,542,080 |
| Size | 436.8 MB | 85.4 MB |
| Events in quadrant A | 3,085,421 | 575,380 |
| Events in quadrant B | 4,093,063 | 566,463 |
| Events in quadrant C | 3,120,007 | 559,947 |
| Events in quadrant D | 3,110,044 | 535,744 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13937 | 3 |
| B | 0 | 16707 | 2 |
| C | 0 | 14259 | 2 |
| D | 0 | 14389 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6810 | 15 | 0.220264% |
| B | 6810 | 33 | 0.484581% |
| C | 6810 | 18 | 0.264317% |
| D | 6810 | 51 | 0.748899% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7744 | 6809 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7744 | 6809 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7744 | 6809 | 5 | 5 | 0.06% | 0.07% |  |
| D | 7744 | 6809 | 44 | 44 | 0.57% | 0.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 70586 | 437.06 | 772 | 759 | 159.8 |
| A | 3 | 1 | 22978 | 139.07 | 772 | 759 | 159.8 |
| A | 0 | 226 | 15045 | 89.42 | 772 | 759 | 159.8 |
| B | 15 | 204 | 552132 | 3580.89 | 786 | 770 | 154.0 |
| B | 7 | 252 | 253472 | 1641.21 | 786 | 770 | 154.0 |
| B | 3 | 0 | 127289 | 821.69 | 786 | 770 | 154.0 |
| C | 14 | 48 | 109716 | 620.08 | 742 | 749 | 175.7 |
| C | 14 | 223 | 67205 | 378.17 | 742 | 749 | 175.7 |
| C | 6 | 80 | 18345 | 100.13 | 742 | 749 | 175.7 |
| D | 13 | 223 | 195021 | 1083.31 | 732 | 711 | 179.4 |
| D | 13 | 114 | 95814 | 530.22 | 732 | 711 | 179.4 |
| D | 5 | 233 | 18180 | 97.39 | 732 | 711 | 179.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
