| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_002T02_9000000444_03275cztM0_level2.evt | modeM0/AS1G05_002T02_9000000444_03275cztM0_level2_quad_clean.evt |
| Size (bytes) | 567,656,640 | 84,456,000 |
| Size | 541.4 MB | 80.5 MB |
| Events in quadrant A | 3,623,632 | 506,002 |
| Events in quadrant B | 5,547,902 | 502,640 |
| Events in quadrant C | 3,772,985 | 510,290 |
| Events in quadrant D | 3,712,948 | 491,840 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16578 | 3 |
| B | 0 | 21968 | 2 |
| C | 0 | 16887 | 2 |
| D | 0 | 17014 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 0 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 0 |
| D | 0 | 160 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7866 | 389 | 4.945334% |
| B | 7866 | 511 | 6.496313% |
| C | 7866 | 363 | 4.614798% |
| D | 7866 | 369 | 4.691076% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8492 | 7868 | 8 | 8 | 0.09% | 0.10% |  |
| B | 8492 | 7868 | 51 | 51 | 0.60% | 0.65% |  |
| C | 8492 | 7868 | 25 | 25 | 0.29% | 0.32% |  |
| D | 8492 | 7868 | 35 | 35 | 0.41% | 0.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 56162 | 295.15 | 911 | 887 | 187.3 |
| A | 0 | 118 | 32134 | 166.85 | 911 | 887 | 187.3 |
| A | 0 | 226 | 12513 | 62.08 | 911 | 887 | 187.3 |
| B | 15 | 204 | 1624874 | 9101.51 | 919 | 894 | 178.4 |
| B | 2 | 249 | 292830 | 1636.14 | 919 | 894 | 178.4 |
| B | 14 | 167 | 32202 | 175.46 | 919 | 894 | 178.4 |
| C | 14 | 223 | 102395 | 491.33 | 894 | 894 | 206.6 |
| C | 6 | 80 | 87466 | 419.06 | 894 | 894 | 206.6 |
| C | 1 | 16 | 59615 | 284.24 | 894 | 894 | 206.6 |
| D | 13 | 223 | 156842 | 727.53 | 888 | 859 | 214.4 |
| D | 13 | 239 | 69120 | 318.38 | 888 | 859 | 214.4 |
| D | 5 | 233 | 40042 | 182.76 | 888 | 859 | 214.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
