| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_241T02_9000000448_03308cztM0_level2.evt | modeM0/AS1G05_241T02_9000000448_03308cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,433,364,480 | 204,154,560 |
| Size | 1.3 GB | 194.7 MB |
| Events in quadrant A | 9,649,316 | 1,226,143 |
| Events in quadrant B | 13,563,105 | 1,220,079 |
| Events in quadrant C | 9,463,023 | 1,218,007 |
| Events in quadrant D | 9,440,808 | 1,199,068 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42089 | 4 |
| B | 0 | 53388 | 3 |
| C | 0 | 41737 | 3 |
| D | 0 | 42278 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 388 | 0 |
| B | 0 | 388 | 0 |
| C | 0 | 388 | 0 |
| D | 0 | 388 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19147 | 681 | 3.556693% |
| B | 19147 | 968 | 5.055622% |
| C | 19147 | 527 | 2.752389% |
| D | 19147 | 430 | 2.245783% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20737 | 19150 | 173 | 173 | 0.83% | 0.90% |  |
| B | 20737 | 19150 | 209 | 209 | 1.01% | 1.09% |  |
| C | 20737 | 19150 | 179 | 179 | 0.86% | 0.93% |  |
| D | 20737 | 19150 | 89 | 89 | 0.43% | 0.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 798831 | 1724.72 | 2248 | 2195 | 461.9 |
| A | 8 | 15 | 117295 | 249.19 | 2248 | 2195 | 461.9 |
| A | 0 | 118 | 63217 | 132.11 | 2248 | 2195 | 461.9 |
| B | 15 | 204 | 3937405 | 8913.37 | 2258 | 2201 | 441.5 |
| B | 3 | 0 | 722563 | 1631.64 | 2258 | 2201 | 441.5 |
| B | 14 | 167 | 61243 | 133.73 | 2258 | 2201 | 441.5 |
| C | 1 | 192 | 461523 | 886.22 | 2197 | 2213 | 518.3 |
| C | 12 | 4 | 175753 | 334.84 | 2197 | 2213 | 518.3 |
| C | 8 | 208 | 152414 | 289.81 | 2197 | 2213 | 518.3 |
| D | 13 | 223 | 432890 | 812.65 | 2193 | 2126 | 530.1 |
| D | 13 | 239 | 186191 | 347.25 | 2193 | 2126 | 530.1 |
| D | 12 | 233 | 172951 | 322.27 | 2193 | 2126 | 530.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
