| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_241T02_9000000448_03316cztM0_level2.evt | modeM0/AS1G05_241T02_9000000448_03316cztM0_level2_quad_clean.evt |
| Size (bytes) | 204,494,400 | 37,437,120 |
| Size | 195.0 MB | 35.7 MB |
| Events in quadrant A | 1,269,913 | 229,904 |
| Events in quadrant B | 2,065,548 | 231,753 |
| Events in quadrant C | 1,345,661 | 235,770 |
| Events in quadrant D | 1,308,123 | 224,052 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5988 | 2 |
| B | 0 | 8203 | 1 |
| C | 0 | 6092 | 1 |
| D | 0 | 6157 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 60 | 0 |
| B | 0 | 60 | 0 |
| C | 0 | 60 | 0 |
| D | 0 | 60 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2966 | 3 | 0.101146% |
| B | 2966 | 84 | 2.832097% |
| C | 2966 | 4 | 0.134862% |
| D | 2966 | 7 | 0.236008% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2966 | 2966 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2966 | 2966 | 61 | 61 | 2.06% | 2.06% |  |
| C | 2966 | 2966 | 1 | 1 | 0.03% | 0.03% |  |
| D | 2966 | 2966 | 3 | 3 | 0.10% | 0.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 3937 | 53.18 | 327 | 320 | 68.0 |
| A | 0 | 226 | 3584 | 47.99 | 327 | 320 | 68.0 |
| A | 12 | 194 | 3382 | 45.02 | 327 | 320 | 68.0 |
| B | 15 | 204 | 580523 | 8930.97 | 329 | 322 | 65.0 |
| B | 15 | 85 | 150147 | 2306.24 | 329 | 322 | 65.0 |
| B | 15 | 54 | 45477 | 695.07 | 329 | 322 | 65.0 |
| C | 6 | 80 | 19962 | 252.2 | 326 | 329 | 77.8 |
| C | 1 | 192 | 17749 | 223.78 | 326 | 329 | 77.8 |
| C | 12 | 4 | 13119 | 164.3 | 326 | 329 | 77.8 |
| D | 12 | 233 | 32040 | 403.48 | 321 | 312 | 78.6 |
| D | 7 | 223 | 20423 | 255.75 | 321 | 312 | 78.6 |
| D | 13 | 223 | 14949 | 186.13 | 321 | 312 | 78.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
