| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_167T01_9000000456_03419cztM0_level2.evt | modeM0/AS1G05_167T01_9000000456_03419cztM0_level2_quad_clean.evt |
| Size (bytes) | 557,124,480 | 92,018,880 |
| Size | 531.3 MB | 87.8 MB |
| Events in quadrant A | 3,543,103 | 581,507 |
| Events in quadrant B | 3,558,012 | 585,710 |
| Events in quadrant C | 5,890,988 | 552,051 |
| Events in quadrant D | 3,385,133 | 558,932 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15523 | 3 |
| B | 0 | 15449 | 2 |
| C | 0 | 22435 | 2 |
| D | 0 | 15548 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7300 | 54 | 0.739726% |
| B | 7300 | 67 | 0.917808% |
| C | 7300 | 836 | 11.452055% |
| D | 7300 | 40 | 0.547945% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7735 | 7301 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7735 | 7301 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7735 | 7301 | 554 | 554 | 7.16% | 7.59% |  |
| D | 7735 | 7301 | 22 | 22 | 0.28% | 0.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 249 | 145112 | 818.8 | 854 | 836 | 176.2 |
| A | 8 | 15 | 83173 | 467.28 | 854 | 836 | 176.2 |
| A | 15 | 174 | 12225 | 64.63 | 854 | 836 | 176.2 |
| B | 15 | 204 | 103530 | 604.41 | 870 | 850 | 169.9 |
| B | 14 | 167 | 49375 | 285.63 | 870 | 850 | 169.9 |
| B | 0 | 229 | 18773 | 105.5 | 870 | 850 | 169.9 |
| C | 14 | 223 | 1481541 | 8087.33 | 782 | 788 | 183.1 |
| C | 7 | 220 | 1214300 | 6627.76 | 782 | 788 | 183.1 |
| C | 1 | 192 | 84598 | 457.74 | 782 | 788 | 183.1 |
| D | 9 | 85 | 97601 | 479.15 | 825 | 800 | 202.0 |
| D | 7 | 46 | 59260 | 289.37 | 825 | 800 | 202.0 |
| D | 2 | 37 | 36739 | 177.89 | 825 | 800 | 202.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
