| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_167T01_9000000456_03427cztM0_level2.evt | modeM0/AS1G05_167T01_9000000456_03427cztM0_level2_quad_clean.evt |
| Size (bytes) | 581,497,920 | 62,904,960 |
| Size | 554.6 MB | 60.0 MB |
| Events in quadrant A | 3,536,162 | 372,831 |
| Events in quadrant B | 4,143,065 | 367,438 |
| Events in quadrant C | 6,151,671 | 346,745 |
| Events in quadrant D | 3,331,877 | 356,477 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14654 | 3 |
| B | 0 | 16587 | 2 |
| C | 0 | 22636 | 2 |
| D | 0 | 14472 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6607 | 105 | 1.589224% |
| B | 6607 | 205 | 3.102770% |
| C | 6607 | 1167 | 17.663085% |
| D | 6607 | 142 | 2.149236% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7667 | 6608 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7667 | 6608 | 67 | 67 | 0.87% | 1.01% |  |
| C | 7667 | 6608 | 780 | 780 | 10.17% | 11.80% |  |
| D | 7667 | 6608 | 58 | 58 | 0.76% | 0.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 249 | 317642 | 1911.31 | 811 | 797 | 165.8 |
| A | 8 | 15 | 31064 | 182.58 | 811 | 797 | 165.8 |
| A | 0 | 118 | 27015 | 158.16 | 811 | 797 | 165.8 |
| B | 15 | 204 | 528599 | 3356.75 | 816 | 798 | 157.2 |
| B | 14 | 167 | 393799 | 2499.44 | 816 | 798 | 157.2 |
| B | 0 | 229 | 17082 | 103.56 | 816 | 798 | 157.2 |
| C | 7 | 220 | 2477290 | 14769.78 | 727 | 733 | 167.7 |
| C | 15 | 208 | 736248 | 4386.49 | 727 | 733 | 167.7 |
| C | 8 | 208 | 58792 | 346.25 | 727 | 733 | 167.7 |
| D | 13 | 223 | 168866 | 879.3 | 784 | 761 | 191.2 |
| D | 9 | 85 | 85404 | 442.74 | 784 | 761 | 191.2 |
| D | 2 | 37 | 29316 | 149.36 | 784 | 761 | 191.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
