| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_209T01_9000000458_03465cztM0_level2.evt | modeM0/AS1G05_209T01_9000000458_03465cztM0_level2_quad_clean.evt |
| Size (bytes) | 526,452,480 | 103,870,080 |
| Size | 502.1 MB | 99.1 MB |
| Events in quadrant A | 3,637,050 | 668,957 |
| Events in quadrant B | 3,532,532 | 676,266 |
| Events in quadrant C | 5,305,935 | 652,645 |
| Events in quadrant D | 2,999,671 | 666,903 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15787 | 2 |
| B | 0 | 15199 | 1 |
| C | 0 | 20936 | 1 |
| D | 0 | 14461 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6909 | 268 | 3.878998% |
| B | 6909 | 138 | 1.997395% |
| C | 6909 | 816 | 11.810682% |
| D | 6909 | 87 | 1.259227% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7094 | 6912 | 77 | 77 | 1.09% | 1.11% |  |
| B | 7094 | 6912 | 17 | 17 | 0.24% | 0.25% |  |
| C | 7094 | 6912 | 627 | 627 | 8.84% | 9.07% |  |
| D | 7094 | 6912 | 17 | 17 | 0.24% | 0.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 539566 | 3465.13 | 749 | 732 | 155.5 |
| A | 0 | 118 | 171027 | 1095.13 | 749 | 732 | 155.5 |
| A | 0 | 226 | 23494 | 146.38 | 749 | 732 | 155.5 |
| B | 15 | 204 | 288447 | 1920.41 | 767 | 747 | 149.8 |
| B | 2 | 249 | 108042 | 716.2 | 767 | 747 | 149.8 |
| B | 14 | 167 | 74518 | 492.43 | 767 | 747 | 149.8 |
| C | 1 | 192 | 2317944 | 14123.72 | 706 | 708 | 164.1 |
| C | 1 | 16 | 129350 | 784.08 | 706 | 708 | 164.1 |
| C | 9 | 144 | 62129 | 374.37 | 706 | 708 | 164.1 |
| D | 5 | 233 | 67512 | 375.55 | 735 | 711 | 177.9 |
| D | 13 | 223 | 41612 | 229.94 | 735 | 711 | 177.9 |
| D | 2 | 37 | 33877 | 186.46 | 735 | 711 | 177.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
