| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_192T01_9000000466_03502cztM0_level2.evt | modeM0/AS1G05_192T01_9000000466_03502cztM0_level2_quad_clean.evt |
| Size (bytes) | 507,769,920 | 67,305,600 |
| Size | 484.2 MB | 64.2 MB |
| Events in quadrant A | 3,285,522 | 409,511 |
| Events in quadrant B | 4,209,064 | 403,390 |
| Events in quadrant C | 4,372,960 | 394,828 |
| Events in quadrant D | 3,087,526 | 394,699 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13759 | 3 |
| B | 0 | 16972 | 2 |
| C | 0 | 17031 | 2 |
| D | 0 | 13435 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6239 | 82 | 1.314313% |
| B | 6239 | 155 | 2.484372% |
| C | 6239 | 303 | 4.856548% |
| D | 6239 | 97 | 1.554736% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7549 | 6239 | 7 | 7 | 0.09% | 0.11% |  |
| B | 7549 | 6239 | 38 | 38 | 0.50% | 0.61% |  |
| C | 7549 | 6239 | 238 | 238 | 3.15% | 3.81% |  |
| D | 7549 | 6239 | 23 | 23 | 0.30% | 0.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 123846 | 768.94 | 792 | 777 | 160.1 |
| A | 8 | 15 | 72214 | 446.34 | 792 | 777 | 160.1 |
| A | 0 | 118 | 21113 | 127.06 | 792 | 777 | 160.1 |
| B | 15 | 204 | 498692 | 3309.54 | 798 | 782 | 150.4 |
| B | 4 | 81 | 394823 | 2619.13 | 798 | 782 | 150.4 |
| B | 2 | 249 | 72832 | 478.9 | 798 | 782 | 150.4 |
| C | 7 | 220 | 905937 | 5153.56 | 765 | 771 | 175.6 |
| C | 14 | 234 | 221505 | 1256.75 | 765 | 771 | 175.6 |
| C | 1 | 192 | 133756 | 757.15 | 765 | 771 | 175.6 |
| D | 13 | 223 | 72888 | 390.35 | 770 | 752 | 184.8 |
| D | 13 | 137 | 51504 | 274.63 | 770 | 752 | 184.8 |
| D | 13 | 239 | 31928 | 168.7 | 770 | 752 | 184.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
