| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_045T01_9000000468_03516cztM0_level2.evt | modeM0/AS1G05_045T01_9000000468_03516cztM0_level2_quad_clean.evt |
| Size (bytes) | 462,536,640 | 99,627,840 |
| Size | 441.1 MB | 95.0 MB |
| Events in quadrant A | 3,418,947 | 649,804 |
| Events in quadrant B | 3,566,830 | 653,002 |
| Events in quadrant C | 3,622,158 | 644,099 |
| Events in quadrant D | 2,968,941 | 627,510 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14479 | 2 |
| B | 0 | 14994 | 1 |
| C | 0 | 15088 | 1 |
| D | 0 | 13356 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6348 | 132 | 2.079395% |
| B | 6348 | 55 | 0.866415% |
| C | 6348 | 136 | 2.142407% |
| D | 6348 | 59 | 0.929427% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7618 | 6349 | 66 | 66 | 0.87% | 1.04% |  |
| B | 7618 | 6349 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7618 | 6348 | 48 | 48 | 0.63% | 0.76% |  |
| D | 7618 | 6348 | 15 | 15 | 0.20% | 0.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 437959 | 2815.93 | 764 | 749 | 155.3 |
| A | 8 | 15 | 18517 | 114.44 | 764 | 749 | 155.3 |
| A | 14 | 238 | 17874 | 110.3 | 764 | 749 | 155.3 |
| B | 15 | 204 | 420529 | 2881.94 | 770 | 754 | 145.7 |
| B | 2 | 249 | 39304 | 264.66 | 770 | 754 | 145.7 |
| B | 4 | 81 | 38641 | 260.11 | 770 | 754 | 145.7 |
| C | 1 | 192 | 562172 | 3261.92 | 743 | 747 | 172.1 |
| C | 15 | 208 | 85247 | 490.95 | 743 | 747 | 172.1 |
| C | 14 | 67 | 28386 | 160.58 | 743 | 747 | 172.1 |
| D | 13 | 223 | 52682 | 288.42 | 748 | 726 | 180.1 |
| D | 13 | 239 | 20573 | 110.18 | 748 | 726 | 180.1 |
| D | 2 | 37 | 18171 | 96.84 | 748 | 726 | 180.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
