| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_045T01_9000000468_03561cztM0_level2.evt | modeM0/AS1G05_045T01_9000000468_03561cztM0_level2_quad_clean.evt |
| Size (bytes) | 412,902,720 | 71,688,960 |
| Size | 393.8 MB | 68.4 MB |
| Events in quadrant A | 2,736,553 | 450,887 |
| Events in quadrant B | 3,489,813 | 442,323 |
| Events in quadrant C | 3,133,198 | 442,435 |
| Events in quadrant D | 2,753,719 | 432,604 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12064 | 2 |
| B | 0 | 14398 | 1 |
| C | 0 | 13031 | 1 |
| D | 0 | 12167 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5754 | 86 | 1.494612% |
| B | 5754 | 66 | 1.147028% |
| C | 5754 | 65 | 1.129649% |
| D | 5754 | 67 | 1.164407% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7039 | 5754 | 5 | 5 | 0.07% | 0.09% |  |
| B | 7039 | 5754 | 6 | 6 | 0.09% | 0.10% |  |
| C | 7039 | 5754 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7039 | 5754 | 3 | 3 | 0.04% | 0.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 54752 | 391.49 | 679 | 665 | 138.2 |
| A | 0 | 50 | 48356 | 345.2 | 679 | 665 | 138.2 |
| A | 0 | 226 | 12224 | 83.67 | 679 | 665 | 138.2 |
| B | 15 | 204 | 615314 | 4723.94 | 686 | 669 | 130.1 |
| B | 4 | 81 | 62238 | 473.2 | 686 | 669 | 130.1 |
| B | 0 | 229 | 28699 | 215.43 | 686 | 669 | 130.1 |
| C | 15 | 208 | 495330 | 3200.07 | 667 | 669 | 154.6 |
| C | 7 | 255 | 13546 | 83.3 | 667 | 669 | 154.6 |
| C | 1 | 16 | 12559 | 76.92 | 667 | 669 | 154.6 |
| D | 8 | 195 | 83449 | 524.03 | 665 | 647 | 158.0 |
| D | 13 | 70 | 35470 | 220.39 | 665 | 647 | 158.0 |
| D | 5 | 233 | 23917 | 147.27 | 665 | 647 | 158.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
