| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_246T03_9000000470_03583cztM0_level2.evt | modeM0/AS1G05_246T03_9000000470_03583cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,230,814,080 | 228,312,000 |
| Size | 1.1 GB | 217.7 MB |
| Events in quadrant A | 8,621,839 | 1,400,858 |
| Events in quadrant B | 9,356,719 | 1,418,035 |
| Events in quadrant C | 9,118,884 | 1,414,347 |
| Events in quadrant D | 8,882,283 | 1,362,720 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 392 | 0 |
| B | 0 | 392 | 0 |
| C | 0 | 392 | 0 |
| D | 0 | 392 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 39211 | 5 |
| B | 0 | 40478 | 4 |
| C | 0 | 40929 | 4 |
| D | 0 | 40872 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19146 | 183 | 0.955813% |
| B | 19146 | 232 | 1.211741% |
| C | 19146 | 209 | 1.091612% |
| D | 19146 | 160 | 0.835684% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20861 | 19151 | 1 | 1 | 0.00% | 0.01% |  |
| B | 20861 | 19151 | 1 | 1 | 0.00% | 0.01% |  |
| C | 20861 | 19151 | 120 | 120 | 0.58% | 0.63% |  |
| D | 20861 | 19151 | 77 | 77 | 0.37% | 0.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 129036 | 283.36 | 2182 | 2126 | 447.9 |
| A | 0 | 118 | 37845 | 79.75 | 2182 | 2126 | 447.9 |
| A | 0 | 226 | 25739 | 52.72 | 2182 | 2126 | 447.9 |
| B | 15 | 204 | 523787 | 1208.97 | 2224 | 2166 | 431.5 |
| B | 14 | 167 | 71114 | 159.8 | 2224 | 2166 | 431.5 |
| B | 4 | 81 | 58336 | 130.19 | 2224 | 2166 | 431.5 |
| C | 15 | 208 | 635512 | 1267.67 | 2141 | 2146 | 499.6 |
| C | 1 | 16 | 66495 | 128.79 | 2141 | 2146 | 499.6 |
| C | 8 | 128 | 28807 | 53.36 | 2141 | 2146 | 499.6 |
| D | 1 | 84 | 201766 | 392.11 | 2123 | 2059 | 509.3 |
| D | 13 | 223 | 182188 | 353.67 | 2123 | 2059 | 509.3 |
| D | 14 | 34 | 122951 | 237.36 | 2123 | 2059 | 509.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
