| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_246T04_9000000472_03595cztM0_level2.evt | modeM0/AS1G05_246T04_9000000472_03595cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,056,602,880 | 154,169,280 |
| Size | 1007.7 MB | 147.0 MB |
| Events in quadrant A | 6,522,435 | 944,478 |
| Events in quadrant B | 7,657,735 | 943,527 |
| Events in quadrant C | 10,670,796 | 898,049 |
| Events in quadrant D | 6,207,815 | 921,805 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29511 | 5 |
| B | 0 | 32473 | 4 |
| C | 0 | 41391 | 4 |
| D | 0 | 29293 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 282 | 0 |
| B | 0 | 282 | 0 |
| C | 0 | 282 | 0 |
| D | 0 | 282 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 13909 | 164 | 1.179093% |
| B | 13909 | 227 | 1.632037% |
| C | 13909 | 1250 | 8.986987% |
| D | 13910 | 67 | 0.481668% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14294 | 13913 | 55 | 55 | 0.38% | 0.40% |  |
| B | 14294 | 13913 | 14 | 14 | 0.10% | 0.10% |  |
| C | 14294 | 13913 | 876 | 876 | 6.13% | 6.30% |  |
| D | 14295 | 13914 | 25 | 25 | 0.17% | 0.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 347697 | 1080.35 | 1568 | 1528 | 320.4 |
| A | 3 | 1 | 71591 | 218.66 | 1568 | 1528 | 320.4 |
| A | 8 | 15 | 30545 | 90.56 | 1568 | 1528 | 320.4 |
| B | 15 | 204 | 1072544 | 3447.97 | 1595 | 1551 | 310.6 |
| B | 4 | 81 | 232191 | 742.53 | 1595 | 1551 | 310.6 |
| B | 0 | 244 | 41713 | 129.3 | 1595 | 1551 | 310.6 |
| C | 2 | 53 | 4398452 | 12669.32 | 1492 | 1497 | 347.1 |
| C | 9 | 247 | 341600 | 979.97 | 1492 | 1497 | 347.1 |
| C | 1 | 16 | 31114 | 85.34 | 1492 | 1497 | 347.1 |
| D | 1 | 84 | 88909 | 234.34 | 1534 | 1485 | 373.1 |
| D | 13 | 239 | 79436 | 208.95 | 1534 | 1485 | 373.1 |
| D | 13 | 223 | 78966 | 207.69 | 1534 | 1485 | 373.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
