| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_248T01_9000000486_03744cztM0_level2.evt | modeM0/AS1G05_248T01_9000000486_03744cztM0_level2_quad_clean.evt |
| Size (bytes) | 481,389,120 | 61,816,320 |
| Size | 459.1 MB | 59.0 MB |
| Events in quadrant A | 4,049,006 | 347,303 |
| Events in quadrant B | 3,804,892 | 359,693 |
| Events in quadrant C | 2,995,433 | 353,243 |
| Events in quadrant D | 3,276,287 | 345,758 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16398 | 2 |
| B | 0 | 15720 | 1 |
| C | 0 | 13734 | 1 |
| D | 0 | 14609 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6681 | 246 | 3.682084% |
| B | 6681 | 103 | 1.541685% |
| C | 6681 | 41 | 0.613681% |
| D | 6681 | 64 | 0.957940% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7726 | 6682 | 188 | 188 | 2.43% | 2.81% |  |
| B | 7726 | 6682 | 60 | 60 | 0.78% | 0.90% |  |
| C | 7726 | 6682 | 19 | 19 | 0.25% | 0.28% |  |
| D | 7726 | 6682 | 33 | 33 | 0.43% | 0.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 818258 | 5177.66 | 763 | 745 | 157.9 |
| A | 0 | 118 | 140101 | 882.6 | 763 | 745 | 157.9 |
| A | 8 | 15 | 64742 | 405.32 | 763 | 745 | 157.9 |
| B | 0 | 173 | 355022 | 2333.84 | 781 | 762 | 151.8 |
| B | 15 | 204 | 212314 | 1393.69 | 781 | 762 | 151.8 |
| B | 14 | 167 | 79453 | 518.41 | 781 | 762 | 151.8 |
| C | 9 | 247 | 67165 | 379.13 | 746 | 750 | 175.2 |
| C | 0 | 239 | 6473 | 32.67 | 746 | 750 | 175.2 |
| C | 13 | 61 | 6427 | 32.41 | 746 | 750 | 175.2 |
| D | 6 | 112 | 101661 | 560.48 | 740 | 719 | 180.1 |
| D | 1 | 20 | 99015 | 545.78 | 740 | 719 | 180.1 |
| D | 13 | 223 | 87273 | 480.59 | 740 | 719 | 180.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
