| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_248T01_9000000486_03758cztM0_level2.evt | modeM0/AS1G05_248T01_9000000486_03758cztM0_level2_quad_clean.evt |
| Size (bytes) | 609,180,480 | 67,253,760 |
| Size | 581.0 MB | 64.1 MB |
| Events in quadrant A | 3,635,460 | 404,928 |
| Events in quadrant B | 3,904,388 | 407,172 |
| Events in quadrant C | 3,083,285 | 400,495 |
| Events in quadrant D | 7,365,835 | 350,068 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15623 | 3 |
| B | 0 | 15944 | 2 |
| C | 0 | 14110 | 2 |
| D | 0 | 26562 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6790 | 89 | 1.310751% |
| B | 6790 | 63 | 0.927835% |
| C | 6790 | 33 | 0.486009% |
| D | 6790 | 1418 | 20.883652% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8615 | 6792 | 38 | 38 | 0.44% | 0.56% |  |
| B | 8615 | 6791 | 4 | 4 | 0.05% | 0.06% |  |
| C | 8615 | 6791 | 16 | 16 | 0.19% | 0.24% |  |
| D | 8615 | 6791 | 1371 | 1371 | 15.91% | 20.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 276731 | 1713.53 | 773 | 756 | 161.1 |
| A | 13 | 251 | 233410 | 1444.55 | 773 | 756 | 161.1 |
| A | 15 | 174 | 49274 | 301.25 | 773 | 756 | 161.1 |
| B | 15 | 204 | 382354 | 2485.9 | 789 | 769 | 153.5 |
| B | 14 | 167 | 299689 | 1947.36 | 789 | 769 | 153.5 |
| B | 0 | 173 | 88133 | 569.15 | 789 | 769 | 153.5 |
| C | 1 | 16 | 121477 | 682.68 | 754 | 758 | 176.8 |
| C | 13 | 61 | 6404 | 31.93 | 754 | 758 | 176.8 |
| C | 8 | 208 | 4452 | 20.89 | 754 | 758 | 176.8 |
| D | 12 | 79 | 3406552 | 20648.75 | 673 | 653 | 164.9 |
| D | 1 | 20 | 927126 | 5616.87 | 673 | 653 | 164.9 |
| D | 13 | 249 | 176711 | 1067.38 | 673 | 653 | 164.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
