| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_152T03_9000000488_03791cztM0_level2.evt | modeM0/AS1G05_152T03_9000000488_03791cztM0_level2_quad_clean.evt |
| Size (bytes) | 493,464,960 | 58,273,920 |
| Size | 470.6 MB | 55.6 MB |
| Events in quadrant A | 3,509,366 | 334,828 |
| Events in quadrant B | 4,278,251 | 332,945 |
| Events in quadrant C | 3,591,830 | 333,268 |
| Events in quadrant D | 3,136,687 | 322,625 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14365 | 3 |
| B | 0 | 16851 | 2 |
| C | 0 | 14928 | 2 |
| D | 0 | 13533 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6312 | 189 | 2.994297% |
| B | 6312 | 234 | 3.707224% |
| C | 6312 | 254 | 4.024081% |
| D | 6313 | 92 | 1.457310% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7552 | 6312 | 74 | 74 | 0.98% | 1.17% |  |
| B | 7552 | 6312 | 116 | 116 | 1.54% | 1.84% |  |
| C | 7552 | 6312 | 158 | 158 | 2.09% | 2.50% |  |
| D | 7553 | 6313 | 21 | 21 | 0.28% | 0.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 225138 | 1398.82 | 792 | 775 | 160.4 |
| A | 0 | 50 | 113983 | 705.81 | 792 | 775 | 160.4 |
| A | 13 | 251 | 31455 | 191.28 | 792 | 775 | 160.4 |
| B | 0 | 173 | 460616 | 3029.68 | 801 | 785 | 151.8 |
| B | 15 | 204 | 421596 | 2772.59 | 801 | 785 | 151.8 |
| B | 14 | 167 | 109401 | 715.63 | 801 | 785 | 151.8 |
| C | 2 | 53 | 614477 | 3519.12 | 754 | 758 | 174.4 |
| C | 12 | 4 | 12590 | 67.85 | 754 | 758 | 174.4 |
| C | 1 | 16 | 8299 | 43.24 | 754 | 758 | 174.4 |
| D | 1 | 84 | 77483 | 416.08 | 763 | 741 | 184.4 |
| D | 13 | 239 | 34472 | 182.88 | 763 | 741 | 184.4 |
| D | 13 | 223 | 26584 | 140.11 | 763 | 741 | 184.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| Veto Counter |  |
