| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_247T01_9000000512_03986cztM0_level2.evt | modeM0/AS1G05_247T01_9000000512_03986cztM0_level2_quad_clean.evt |
| Size (bytes) | 481,726,080 | 105,298,560 |
| Size | 459.4 MB | 100.4 MB |
| Events in quadrant A | 3,532,807 | 678,106 |
| Events in quadrant B | 3,244,057 | 686,269 |
| Events in quadrant C | 2,972,446 | 688,275 |
| Events in quadrant D | 4,371,540 | 656,093 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15474 | 2 |
| B | 0 | 14344 | 1 |
| C | 0 | 14075 | 1 |
| D | 0 | 17820 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6898 | 116 | 1.681647% |
| B | 6898 | 44 | 0.637866% |
| C | 6898 | 21 | 0.304436% |
| D | 6898 | 139 | 2.015077% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7253 | 6899 | 48 | 48 | 0.66% | 0.70% |  |
| B | 7253 | 6899 | 7 | 7 | 0.10% | 0.10% |  |
| C | 7253 | 6899 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7253 | 6899 | 106 | 106 | 1.46% | 1.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 267238 | 1715.04 | 755 | 736 | 155.4 |
| A | 4 | 48 | 209807 | 1345.45 | 755 | 736 | 155.4 |
| A | 0 | 118 | 103098 | 658.74 | 755 | 736 | 155.4 |
| B | 14 | 167 | 107248 | 721.33 | 765 | 744 | 147.6 |
| B | 15 | 204 | 56750 | 379.32 | 765 | 744 | 147.6 |
| B | 3 | 0 | 40530 | 269.46 | 765 | 744 | 147.6 |
| C | 9 | 144 | 66062 | 378.82 | 740 | 741 | 172.4 |
| C | 13 | 61 | 6276 | 32.1 | 740 | 741 | 172.4 |
| C | 9 | 247 | 4989 | 24.64 | 740 | 741 | 172.4 |
| D | 2 | 63 | 1071992 | 6048.6 | 735 | 713 | 177.1 |
| D | 2 | 232 | 155755 | 875.39 | 735 | 713 | 177.1 |
| D | 13 | 223 | 99787 | 559.39 | 735 | 713 | 177.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
