| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_247T01_9000000512_03989cztM0_level2.evt | modeM0/AS1G05_247T01_9000000512_03989cztM0_level2_quad_clean.evt |
| Size (bytes) | 420,013,440 | 96,134,400 |
| Size | 400.6 MB | 91.7 MB |
| Events in quadrant A | 3,528,523 | 621,687 |
| Events in quadrant B | 3,343,128 | 619,147 |
| Events in quadrant C | 2,630,645 | 624,120 |
| Events in quadrant D | 2,793,422 | 610,899 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14868 | 2 |
| B | 0 | 14111 | 1 |
| C | 0 | 12574 | 1 |
| D | 0 | 13053 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6234 | 208 | 3.336542% |
| B | 6234 | 92 | 1.475778% |
| C | 6234 | 21 | 0.336862% |
| D | 6234 | 37 | 0.593519% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7104 | 6235 | 118 | 118 | 1.66% | 1.89% |  |
| B | 7104 | 6235 | 62 | 62 | 0.87% | 0.99% |  |
| C | 7104 | 6235 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7104 | 6235 | 18 | 18 | 0.25% | 0.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 809226 | 5780.47 | 681 | 665 | 139.9 |
| A | 0 | 118 | 39876 | 280.32 | 681 | 665 | 139.9 |
| A | 8 | 15 | 23985 | 166.72 | 681 | 665 | 139.9 |
| B | 14 | 167 | 210762 | 1584.6 | 690 | 673 | 132.6 |
| B | 10 | 16 | 177621 | 1334.64 | 690 | 673 | 132.6 |
| B | 3 | 0 | 127667 | 957.86 | 690 | 673 | 132.6 |
| C | 10 | 65 | 12173 | 73.8 | 665 | 667 | 155.9 |
| C | 8 | 128 | 8044 | 47.32 | 665 | 667 | 155.9 |
| C | 1 | 16 | 5800 | 32.92 | 665 | 667 | 155.9 |
| D | 9 | 82 | 104600 | 653.81 | 661 | 641 | 159.0 |
| D | 2 | 232 | 93413 | 583.45 | 661 | 641 | 159.0 |
| D | 13 | 248 | 20361 | 124.02 | 661 | 641 | 159.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
