| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_173T01_9000000514_04025cztM0_level2.evt | modeM0/AS1G05_173T01_9000000514_04025cztM0_level2_quad_clean.evt |
| Size (bytes) | 413,536,320 | 56,494,080 |
| Size | 394.4 MB | 53.9 MB |
| Events in quadrant A | 3,046,350 | 317,277 |
| Events in quadrant B | 3,222,693 | 322,041 |
| Events in quadrant C | 2,894,357 | 318,894 |
| Events in quadrant D | 2,925,067 | 305,493 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13415 | 3 |
| B | 0 | 13714 | 2 |
| C | 0 | 13082 | 2 |
| D | 0 | 13373 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6399 | 59 | 0.922019% |
| B | 6399 | 61 | 0.953274% |
| C | 6399 | 23 | 0.359431% |
| D | 6399 | 55 | 0.859509% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7594 | 6400 | 13 | 13 | 0.17% | 0.20% |  |
| B | 7594 | 6400 | 19 | 19 | 0.25% | 0.30% |  |
| C | 7594 | 6400 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7594 | 6400 | 15 | 15 | 0.20% | 0.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 55324 | 353.46 | 760 | 743 | 154.4 |
| A | 7 | 16 | 19796 | 123.39 | 760 | 743 | 154.4 |
| A | 8 | 15 | 17337 | 107.46 | 760 | 743 | 154.4 |
| B | 14 | 167 | 155103 | 1049.84 | 769 | 750 | 147.0 |
| B | 4 | 81 | 72716 | 489.48 | 769 | 750 | 147.0 |
| B | 15 | 204 | 13391 | 85.98 | 769 | 750 | 147.0 |
| C | 1 | 16 | 10608 | 57.88 | 736 | 741 | 170.5 |
| C | 13 | 61 | 6182 | 31.92 | 736 | 741 | 170.5 |
| C | 12 | 4 | 4183 | 20.19 | 736 | 741 | 170.5 |
| D | 2 | 14 | 39858 | 224.22 | 728 | 706 | 174.6 |
| D | 13 | 53 | 37075 | 208.29 | 728 | 706 | 174.6 |
| D | 2 | 232 | 36004 | 202.15 | 728 | 706 | 174.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
