| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_246T03_9000000516_04036cztM0_level2.evt | modeM0/AS1G05_246T03_9000000516_04036cztM0_level2_quad_clean.evt |
| Size (bytes) | 516,337,920 | 76,432,320 |
| Size | 492.4 MB | 72.9 MB |
| Events in quadrant A | 3,385,107 | 484,762 |
| Events in quadrant B | 4,038,076 | 482,088 |
| Events in quadrant C | 2,842,067 | 494,178 |
| Events in quadrant D | 4,941,635 | 410,528 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14445 | 3 |
| B | 0 | 16321 | 2 |
| C | 0 | 12973 | 2 |
| D | 0 | 19401 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6336 | 84 | 1.325758% |
| B | 6336 | 194 | 3.061869% |
| C | 6336 | 30 | 0.473485% |
| D | 6336 | 766 | 12.089646% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7561 | 6337 | 57 | 57 | 0.75% | 0.90% |  |
| B | 7561 | 6337 | 167 | 167 | 2.21% | 2.64% |  |
| C | 7561 | 6337 | 9 | 9 | 0.12% | 0.14% |  |
| D | 7561 | 6337 | 701 | 701 | 9.27% | 11.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 221585 | 1495.99 | 721 | 707 | 147.6 |
| A | 0 | 50 | 194889 | 1315.18 | 721 | 707 | 147.6 |
| A | 8 | 15 | 102833 | 691.69 | 721 | 707 | 147.6 |
| B | 14 | 167 | 663438 | 4812.75 | 727 | 710 | 137.7 |
| B | 10 | 16 | 268574 | 1945.24 | 727 | 710 | 137.7 |
| B | 15 | 204 | 132904 | 960.0 | 727 | 710 | 137.7 |
| C | 7 | 221 | 27701 | 163.12 | 716 | 720 | 165.4 |
| C | 9 | 144 | 8358 | 46.18 | 716 | 720 | 165.4 |
| C | 12 | 4 | 7742 | 42.45 | 716 | 720 | 165.4 |
| D | 13 | 53 | 1678637 | 10886.33 | 644 | 625 | 154.1 |
| D | 11 | 132 | 474913 | 3077.01 | 644 | 625 | 154.1 |
| D | 2 | 232 | 256942 | 1662.89 | 644 | 625 | 154.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
