| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_246T03_9000000516_04038cztM0_level2.evt | modeM0/AS1G05_246T03_9000000516_04038cztM0_level2_quad_clean.evt |
| Size (bytes) | 473,011,200 | 78,272,640 |
| Size | 451.1 MB | 74.6 MB |
| Events in quadrant A | 3,778,681 | 464,916 |
| Events in quadrant B | 3,648,352 | 494,732 |
| Events in quadrant C | 2,908,712 | 501,191 |
| Events in quadrant D | 3,562,798 | 470,894 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15585 | 3 |
| B | 0 | 15155 | 2 |
| C | 0 | 13075 | 2 |
| D | 0 | 15153 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6278 | 338 | 5.383880% |
| B | 6278 | 192 | 3.058299% |
| C | 6278 | 35 | 0.557502% |
| D | 6278 | 103 | 1.640650% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7603 | 6279 | 268 | 268 | 3.52% | 4.27% |  |
| B | 7603 | 6279 | 142 | 142 | 1.87% | 2.26% |  |
| C | 7603 | 6279 | 15 | 15 | 0.20% | 0.24% |  |
| D | 7603 | 6279 | 101 | 101 | 1.33% | 1.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 835232 | 5830.93 | 697 | 682 | 143.1 |
| A | 8 | 15 | 107329 | 745.13 | 697 | 682 | 143.1 |
| A | 0 | 199 | 61889 | 427.65 | 697 | 682 | 143.1 |
| B | 10 | 16 | 608320 | 4484.01 | 727 | 711 | 135.5 |
| B | 4 | 142 | 70125 | 512.26 | 727 | 711 | 135.5 |
| B | 14 | 167 | 57359 | 418.05 | 727 | 711 | 135.5 |
| C | 12 | 4 | 77810 | 460.08 | 718 | 721 | 167.6 |
| C | 9 | 144 | 13322 | 75.2 | 718 | 721 | 167.6 |
| C | 1 | 16 | 11903 | 66.74 | 718 | 721 | 167.6 |
| D | 2 | 232 | 370847 | 2187.85 | 699 | 679 | 169.2 |
| D | 4 | 160 | 343743 | 2027.65 | 699 | 679 | 169.2 |
| D | 11 | 132 | 81495 | 477.66 | 699 | 679 | 169.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
