| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_167T01_9000000528_04115cztM0_level2.evt | modeM0/AS1G05_167T01_9000000528_04115cztM0_level2_quad_clean.evt |
| Size (bytes) | 459,930,240 | 93,479,040 |
| Size | 438.6 MB | 89.1 MB |
| Events in quadrant A | 3,435,168 | 586,707 |
| Events in quadrant B | 3,394,441 | 589,603 |
| Events in quadrant C | 3,342,758 | 587,084 |
| Events in quadrant D | 3,268,049 | 567,154 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15283 | 2 |
| B | 0 | 14939 | 1 |
| C | 0 | 15075 | 3 |
| D | 0 | 15187 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7182 | 137 | 1.907547% |
| B | 7182 | 137 | 1.907547% |
| C | 7181 | 49 | 0.682356% |
| D | 7182 | 56 | 0.779727% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7286 | 7181 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7287 | 7182 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7286 | 7181 | 15 | 15 | 0.21% | 0.21% |  |
| D | 7286 | 7181 | 16 | 16 | 0.22% | 0.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 199 | 149732 | 859.33 | 837 | 820 | 173.3 |
| A | 14 | 111 | 34238 | 192.85 | 837 | 820 | 173.3 |
| A | 0 | 226 | 21020 | 116.57 | 837 | 820 | 173.3 |
| B | 14 | 167 | 67783 | 412.85 | 849 | 831 | 162.2 |
| B | 15 | 204 | 27678 | 165.55 | 849 | 831 | 162.2 |
| B | 12 | 111 | 15222 | 88.74 | 849 | 831 | 162.2 |
| C | 14 | 234 | 124829 | 648.28 | 818 | 824 | 191.3 |
| C | 10 | 65 | 9838 | 47.12 | 818 | 824 | 191.3 |
| C | 12 | 4 | 8939 | 42.42 | 818 | 824 | 191.3 |
| D | 10 | 172 | 62814 | 314.87 | 810 | 787 | 197.0 |
| D | 13 | 239 | 60257 | 301.89 | 810 | 787 | 197.0 |
| D | 2 | 14 | 50345 | 251.57 | 810 | 787 | 197.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
