| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_195T01_9000000530_04127cztM0_level2.evt | modeM0/AS1G05_195T01_9000000530_04127cztM0_level2_quad_clean.evt |
| Size (bytes) | 597,263,040 | 80,962,560 |
| Size | 569.6 MB | 77.2 MB |
| Events in quadrant A | 3,635,331 | 521,010 |
| Events in quadrant B | 6,157,071 | 478,589 |
| Events in quadrant C | 3,306,715 | 513,745 |
| Events in quadrant D | 4,542,974 | 479,209 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15414 | 3 |
| B | 0 | 22766 | 2 |
| C | 0 | 14516 | 2 |
| D | 0 | 18541 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6574 | 144 | 2.190447% |
| B | 6574 | 1159 | 17.630058% |
| C | 6574 | 63 | 0.958321% |
| D | 6574 | 675 | 10.267721% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7579 | 6575 | 103 | 103 | 1.36% | 1.57% |  |
| B | 7579 | 6575 | 1067 | 1067 | 14.08% | 16.23% |  |
| C | 7579 | 6575 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7579 | 6575 | 690 | 690 | 9.10% | 10.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 395636 | 2600.05 | 733 | 717 | 151.9 |
| A | 0 | 199 | 313660 | 2060.34 | 733 | 717 | 151.9 |
| A | 0 | 226 | 38609 | 249.47 | 733 | 717 | 151.9 |
| B | 10 | 16 | 3013353 | 22718.12 | 697 | 681 | 132.6 |
| B | 15 | 204 | 139297 | 1045.28 | 697 | 681 | 132.6 |
| B | 5 | 184 | 136444 | 1023.77 | 697 | 681 | 132.6 |
| C | 9 | 144 | 516463 | 3112.03 | 713 | 714 | 165.7 |
| C | 13 | 61 | 5990 | 31.84 | 713 | 714 | 165.7 |
| C | 12 | 4 | 3667 | 17.82 | 713 | 714 | 165.7 |
| D | 2 | 37 | 1096677 | 6564.69 | 688 | 668 | 167.0 |
| D | 12 | 212 | 248301 | 1483.23 | 688 | 668 | 167.0 |
| D | 4 | 95 | 194777 | 1162.64 | 688 | 668 | 167.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
