| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_195T01_9000000530_04130cztM0_level2.evt | modeM0/AS1G05_195T01_9000000530_04130cztM0_level2_quad_clean.evt |
| Size (bytes) | 495,282,240 | 87,840,000 |
| Size | 472.3 MB | 83.8 MB |
| Events in quadrant A | 3,738,521 | 537,276 |
| Events in quadrant B | 3,861,242 | 537,639 |
| Events in quadrant C | 3,261,875 | 536,478 |
| Events in quadrant D | 3,623,498 | 521,946 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16617 | 3 |
| B | 0 | 16692 | 2 |
| C | 0 | 15505 | 2 |
| D | 0 | 16678 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7565 | 197 | 2.604098% |
| B | 7565 | 131 | 1.731659% |
| C | 7565 | 80 | 1.057502% |
| D | 7565 | 121 | 1.599471% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7820 | 7567 | 103 | 103 | 1.32% | 1.36% |  |
| B | 7820 | 7567 | 18 | 18 | 0.23% | 0.24% |  |
| C | 7820 | 7567 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7820 | 7567 | 43 | 43 | 0.55% | 0.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 234 | 250792 | 1445.21 | 845 | 825 | 173.0 |
| A | 0 | 50 | 140159 | 805.57 | 845 | 825 | 173.0 |
| A | 0 | 118 | 43978 | 249.49 | 845 | 825 | 173.0 |
| B | 15 | 204 | 234754 | 1403.93 | 863 | 841 | 166.6 |
| B | 4 | 48 | 93928 | 558.7 | 863 | 841 | 166.6 |
| B | 10 | 16 | 64443 | 381.73 | 863 | 841 | 166.6 |
| C | 13 | 61 | 7029 | 31.48 | 833 | 834 | 196.8 |
| C | 10 | 65 | 2948 | 10.74 | 833 | 834 | 196.8 |
| C | 9 | 144 | 2232 | 7.1 | 833 | 834 | 196.8 |
| D | 13 | 53 | 121159 | 603.59 | 821 | 794 | 199.4 |
| D | 4 | 95 | 118664 | 591.07 | 821 | 794 | 199.4 |
| D | 13 | 72 | 51318 | 253.36 | 821 | 794 | 199.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
