| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_240T01_9000000536_04162cztM0_level2.evt | modeM0/AS1G05_240T01_9000000536_04162cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,274,002,560 | 189,483,840 |
| Size | 1.2 GB | 180.7 MB |
| Events in quadrant A | 9,978,669 | 1,115,399 |
| Events in quadrant B | 9,191,461 | 1,141,688 |
| Events in quadrant C | 8,538,265 | 1,135,129 |
| Events in quadrant D | 9,647,410 | 1,095,197 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 366 | 0 |
| B | 0 | 366 | 0 |
| C | 0 | 366 | 0 |
| D | 0 | 366 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42245 | 4 |
| B | 0 | 39582 | 7 |
| C | 0 | 38290 | 3 |
| D | 0 | 41757 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18158 | 751 | 4.135918% |
| B | 18157 | 216 | 1.189624% |
| C | 18158 | 183 | 1.007820% |
| D | 18158 | 558 | 3.073026% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19858 | 18161 | 521 | 521 | 2.62% | 2.87% |  |
| B | 19858 | 18161 | 14 | 14 | 0.07% | 0.08% |  |
| C | 19858 | 18161 | 59 | 59 | 0.30% | 0.32% |  |
| D | 19858 | 18161 | 388 | 388 | 1.95% | 2.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 199 | 1204409 | 2848.76 | 2070 | 2026 | 422.1 |
| A | 3 | 1 | 308119 | 725.22 | 2070 | 2026 | 422.1 |
| A | 0 | 50 | 195027 | 457.27 | 2070 | 2026 | 422.1 |
| B | 14 | 167 | 705140 | 1723.88 | 2107 | 2051 | 407.9 |
| B | 10 | 16 | 138150 | 333.7 | 2107 | 2051 | 407.9 |
| B | 4 | 48 | 83067 | 198.64 | 2107 | 2051 | 407.9 |
| C | 9 | 144 | 509413 | 1071.9 | 2036 | 2041 | 473.3 |
| C | 10 | 65 | 39500 | 79.14 | 2036 | 2041 | 473.3 |
| C | 7 | 222 | 17210 | 32.05 | 2036 | 2041 | 473.3 |
| D | 2 | 63 | 608958 | 1233.9 | 2016 | 1954 | 491.9 |
| D | 13 | 239 | 516339 | 1045.62 | 2016 | 1954 | 491.9 |
| D | 2 | 232 | 368522 | 745.15 | 2016 | 1954 | 491.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
