| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_240T01_9000000536_04163cztM0_level2.evt | modeM0/AS1G05_240T01_9000000536_04163cztM0_level2_quad_clean.evt |
| Size (bytes) | 496,566,720 | 66,669,120 |
| Size | 473.6 MB | 63.6 MB |
| Events in quadrant A | 2,969,369 | 400,736 |
| Events in quadrant B | 3,374,918 | 402,448 |
| Events in quadrant C | 2,698,408 | 401,580 |
| Events in quadrant D | 5,581,090 | 387,414 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12938 | 2 |
| B | 0 | 14036 | 1 |
| C | 0 | 12414 | 3 |
| D | 0 | 20885 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6100 | 78 | 1.278689% |
| B | 6100 | 149 | 2.442623% |
| C | 6099 | 26 | 0.426299% |
| D | 6100 | 923 | 15.131148% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7035 | 6101 | 25 | 25 | 0.36% | 0.41% |  |
| B | 7035 | 6101 | 97 | 97 | 1.38% | 1.59% |  |
| C | 7035 | 6101 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7035 | 6101 | 944 | 944 | 13.42% | 15.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 199 | 85678 | 587.49 | 702 | 684 | 144.7 |
| A | 3 | 1 | 73541 | 503.6 | 702 | 684 | 144.7 |
| A | 0 | 50 | 37727 | 256.05 | 702 | 684 | 144.7 |
| B | 10 | 16 | 315572 | 2301.51 | 701 | 685 | 136.8 |
| B | 14 | 167 | 227455 | 1657.46 | 701 | 685 | 136.8 |
| B | 4 | 48 | 57731 | 416.95 | 701 | 685 | 136.8 |
| C | 12 | 4 | 31981 | 197.88 | 679 | 683 | 158.2 |
| C | 9 | 144 | 12208 | 72.87 | 679 | 683 | 158.2 |
| C | 13 | 61 | 5532 | 30.66 | 679 | 683 | 158.2 |
| D | 2 | 232 | 2843823 | 17676.28 | 663 | 644 | 160.8 |
| D | 13 | 239 | 153567 | 950.74 | 663 | 644 | 160.8 |
| D | 10 | 172 | 21014 | 126.64 | 663 | 644 | 160.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
