| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_240T01_9000000536_04184cztM0_level2.evt | modeM0/AS1G05_240T01_9000000536_04184cztM0_level2_quad_clean.evt |
| Size (bytes) | 490,141,440 | 55,437,120 |
| Size | 467.4 MB | 52.9 MB |
| Events in quadrant A | 3,936,808 | 311,819 |
| Events in quadrant B | 3,235,792 | 320,703 |
| Events in quadrant C | 2,984,883 | 307,900 |
| Events in quadrant D | 4,258,083 | 297,200 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15909 | 3 |
| B | 0 | 13490 | 2 |
| C | 0 | 13031 | 2 |
| D | 0 | 16965 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6313 | 211 | 3.342310% |
| B | 6313 | 98 | 1.552352% |
| C | 6313 | 41 | 0.649454% |
| D | 6313 | 192 | 3.041343% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7553 | 6314 | 62 | 62 | 0.82% | 0.98% |  |
| B | 7553 | 6314 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7553 | 6314 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7553 | 6314 | 112 | 112 | 1.48% | 1.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 383433 | 2392.68 | 788 | 771 | 159.9 |
| A | 0 | 118 | 336780 | 2100.97 | 788 | 771 | 159.9 |
| A | 0 | 199 | 81795 | 506.62 | 788 | 771 | 159.9 |
| B | 10 | 16 | 25573 | 161.12 | 802 | 786 | 153.8 |
| B | 7 | 252 | 21914 | 137.34 | 802 | 786 | 153.8 |
| B | 0 | 183 | 18966 | 118.18 | 802 | 786 | 153.8 |
| C | 13 | 61 | 6378 | 31.72 | 762 | 766 | 176.9 |
| C | 10 | 65 | 4419 | 20.65 | 762 | 766 | 176.9 |
| C | 12 | 4 | 2877 | 11.93 | 762 | 766 | 176.9 |
| D | 13 | 46 | 921094 | 5048.84 | 754 | 733 | 182.3 |
| D | 12 | 233 | 249971 | 1367.25 | 754 | 733 | 182.3 |
| D | 13 | 239 | 71419 | 387.76 | 754 | 733 | 182.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
