| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_240T01_9000000536_04238cztM0_level2.evt | modeM0/AS1G05_240T01_9000000536_04238cztM0_level2_quad_clean.evt |
| Size (bytes) | 717,007,680 | 78,503,040 |
| Size | 683.8 MB | 74.9 MB |
| Events in quadrant A | 3,114,687 | 501,576 |
| Events in quadrant B | 4,391,352 | 497,276 |
| Events in quadrant C | 2,988,614 | 492,145 |
| Events in quadrant D | 10,771,815 | 422,687 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13680 | 86 |
| B | 0 | 17749 | 88 |
| C | 0 | 13601 | 87 |
| D | 0 | 36897 | 329 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6644 | 37 | 0.556893% |
| B | 6645 | 64 | 0.963130% |
| C | 6645 | 20 | 0.300978% |
| D | 6633 | 1841 | 27.755164% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7843 | 6654 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7843 | 6653 | 11 | 11 | 0.14% | 0.17% |  |
| C | 7843 | 6655 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7844 | 6639 | 2353 | 2353 | 30.00% | 35.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 149 | 44236 | 266.52 | 795 | 779 | 163.1 |
| A | 0 | 226 | 12003 | 68.84 | 795 | 779 | 163.1 |
| A | 12 | 194 | 8294 | 46.09 | 795 | 779 | 163.1 |
| B | 3 | 0 | 1076297 | 7078.5 | 792 | 776 | 151.9 |
| B | 10 | 16 | 149431 | 978.37 | 792 | 776 | 151.9 |
| B | 15 | 204 | 50442 | 326.87 | 792 | 776 | 151.9 |
| C | 13 | 61 | 6146 | 30.39 | 763 | 767 | 177.0 |
| C | 9 | 144 | 5752 | 28.17 | 763 | 767 | 177.0 |
| C | 10 | 65 | 1999 | 6.96 | 763 | 767 | 177.0 |
| D | 2 | 63 | 7074514 | 40987.55 | 715 | 695 | 172.6 |
| D | 11 | 132 | 737663 | 4270.18 | 715 | 695 | 172.6 |
| D | 13 | 239 | 155977 | 899.74 | 715 | 695 | 172.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
