| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_240T01_9000000536_04252cztM0_level2.evt | modeM0/AS1G05_240T01_9000000536_04252cztM0_level2_quad_clean.evt |
| Size (bytes) | 574,318,080 | 77,719,680 |
| Size | 547.7 MB | 74.1 MB |
| Events in quadrant A | 4,478,740 | 464,519 |
| Events in quadrant B | 3,359,065 | 484,107 |
| Events in quadrant C | 2,978,686 | 479,143 |
| Events in quadrant D | 6,124,265 | 459,626 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17809 | 12 |
| B | 0 | 14342 | 14 |
| C | 0 | 13599 | 9 |
| D | 0 | 22758 | 9 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6678 | 441 | 6.603774% |
| B | 6677 | 50 | 0.748839% |
| C | 6677 | 30 | 0.449304% |
| D | 6678 | 482 | 7.217730% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7790 | 6681 | 360 | 360 | 4.62% | 5.39% |  |
| B | 7790 | 6681 | 12 | 12 | 0.15% | 0.18% |  |
| C | 7790 | 6681 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7791 | 6682 | 392 | 392 | 5.03% | 5.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 199 | 1310545 | 8322.27 | 766 | 749 | 157.4 |
| A | 0 | 226 | 124472 | 786.12 | 766 | 749 | 157.4 |
| A | 0 | 149 | 60231 | 377.94 | 766 | 749 | 157.4 |
| B | 14 | 167 | 189602 | 1235.83 | 784 | 766 | 152.8 |
| B | 15 | 204 | 39199 | 251.52 | 784 | 766 | 152.8 |
| B | 10 | 16 | 36968 | 236.92 | 784 | 766 | 152.8 |
| C | 9 | 144 | 21977 | 119.92 | 756 | 761 | 176.9 |
| C | 13 | 61 | 6170 | 30.57 | 756 | 761 | 176.9 |
| C | 9 | 54 | 2691 | 10.91 | 756 | 761 | 176.9 |
| D | 4 | 95 | 2493326 | 13947.79 | 743 | 723 | 178.7 |
| D | 2 | 136 | 346915 | 1937.18 | 743 | 723 | 178.7 |
| D | 13 | 239 | 141942 | 790.22 | 743 | 723 | 178.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
